RedMax BCZ2401S - Page 57

57
Key# Part Number Description Q'ty
1 848-F08-1210 CYLINDER COMP. 1
2 848-F08-12C0 • COVER, TR-S 1
3 848-F08-12D0 • COVER, TR-F 1
4 848-F08-12E0 • GASKET, TR 2
5 848-814-1000 • BOLT 4
6 T1551-12211 GASKET, base 1
7 4820-12130 BOLT TORX 4
8 848-F08-14A1 INSULATOR 1
9 848-F08-14B2 GASKET, insu 1
10 848-F08-14C0 GASKET, carb 1
11 T4950-52001 BOLT TORX 4
12 T1551-21101 CRANKCASE COMP. 1
13 2629-21130 • PIN 3
14 T1551-21141 GASKET, case 1
15 06030-06001 BEARING 2
16 4810-21210 SEAL 1
17 1850-21220 SEAL 1
18 04065-02812 RING 1
19 4820-13180 BOLT TORX 3
20 848-F08-41A2 PISTON 1
21 848-8C3-4101 RING 2
22 1600-41310 PIN 1
23 1260-41320 RING 2
24 T1551-41410 BEARING 1
25 1101-41340 WASHER 2
26 848-F08-4201 CRANKSHAFT COMP. 1
27 1650-43230 NUT 1
28 1000-43240 KEY 1
29 4810-71110 ROTOR 1
30 848-F08-7131 COIL ASSY 1
31 4810-72111 • CAP 1
32 848-F08-71G0 • SPRING 1
33 848-8MX-0700 • TUBE 1
34 1260-71261 SPACER 2
35 4820-72150 BOLT TORX 2
36 848-F08-8101 CARBURETOR ASSY 1
37 848-F60-0631 • REBUILD KIT 1
38 1850-81450 • • BODY ASSY 1
39 4810-06021 • • GASKET KIT 1
40 1850-81490 • BODY 1
41 1850-81520 • COVER 1
42 1751-81510 • PUMP 1
44 1751-81130 • RING 1
45 1881-81140 • SWIVEL 1
46 1752-81110 • SCREW 2
47 5500-81120 • BRACKET 1
48 1751-81180 • NUT 1
49 1918-81170 • SCREW 1
50 1850-81530 • SCREW 4
51 5500-81160 • WASHER 1
52 4820-15310 BOLT TORX 2
53 1950-86120 CLIP 1
54 848-F08-1510 MUFFLER ASSY 1
56 4810-15140 • ARRESTER 1
57 4820-15310 BOLT TORX 2
58 848-F08-15C1 GASKET, muff 1
59 848-F00-15D1 PLATE 1
60 4820-12350 BOLT TORX 2
Key# Part Number Description Q'ty
61 848-F00-5301 HOUSING ASSY 1
62 T1551-31100 • HOUSING COMP. 1
63 T1551-31110 • • HOUSING 1
64 T1700-31212 • • BRACKET(A) 1
65 T1700-31221 • • BRACKET (B) 1
66 T1700-31232 • • CUSHION 1
67 848-F30-51A1 • DRUM 1
68 04065-02812 • RING 1
69 T1701-31150 • BEARING 1
70 04064-01210 • SNAP RING 1
71 4820-13180 • BOLT TORX 2
73 4820-85510 BOLT TORX 4
74 848-F08-31A1 COVER, engine 1
75 848-815-1002 BOLT TORX 2
76 T1551-51111 SHOE 2
77 4820-51220 SPRING 1
78 1140-51250 SCREW 2
79 1140-51230 WASHER 2
80 1140-51242 WASHER 2
81 T1551-73200 CORD COMP. 1
82 3699-91867 SPARKPLUG (CMR7H) 1
83 4810-72120 GROMET 1
84 T1551-75100 RECOIL ASSY 1
85 4500-75120 • REEL 1
86 4500-75150 • SCREW 1
87 1850-75130 • SPRING 1
88 4500-75180 • COLLAR 1
89 4500-75190 • ARM 1
90 4810-75160 • ROPE 1
91 3330-75421 • KNOB 1
92 4810-75170 • PLATE 1
93 4500-75210 PULLEY 1
94 4820-32120 BOLT TORX 4
95 848-F00-8310 BODY ASSY 1
96 T1512-82130 • PLATE, choke 1
97 T1600-82140 • LEVER 1
98 T1108-82190 • SCREW 1
99 T1551-82170 ELEMENT 1
100 848-F62-8320 COVER ASSY 1
101 T1108-82220 • KNOB 1
102a 848-F00-8500 TANK ASSY 1
102b 848-F0M-8500 TANK ASSY (CA Only) 1
103 T1015-85202 • CAP ASSY 1
104 4500-85300 • • HOLDER ASSY 1
105 4500-85220 • • PACKING 1
106 5601-85260 • • FILTER 1
107 4820-85260 • • STOPPER 1
108 T1551-85300 • PIPE COMP. 1
109 3302-85400 • FILTER 1
110 1260-85460 • CLIP 1
111 4820-85510 BOLT TORX 3
112 T1551-31910 GUARD, tank 1
113 T1551-75410 LABEL, recoil 1
114 T1551-31130 LABEL, cover 1
118 4500-81910 COVER 1
119 4820-12350 BOLT 1
120 848-F08-12G0 PLATE 1
121 4820-12350 BOLT 2
Fig.2 ENGINE UNIT BCZ2401S/BCZ2401S-CA (S/N 50200101 and up)
