RedMax BCZ2500S - Fig.2 DRIVE UNIT BCZ2500 SW (S;N 100001 and up); Drive Unit Parts List (BCZ2500 SW)

101 9” 22-tooth SST229 1
102 9” 24-tooth SST249 1
103 8” 8-tooth SGB088 1
104 9” 8-tooth SGB089 1
105 8” 4-tooth SGB048 1
106 9” 4-tooth SGB049 1
107 COVER 3540-13283 1
Key# Description Part Number Q'ty
1 PIPE-COMP, 1500xø24xT1.7 T3002-12101 1
2
SHAFT, 1536xø7, spline 7T 3520-12213 1
3 GEARCASE-ASSY T3002-13001 1
4 • GEARCASE 6489-13110 1
5 • BEARING T3300-13521 1
6 • BEARING T3403-13510 1
7 • RING 04065-02612 1
8 • SEAL 3565-13130 1
9 • SHAFT T3002-13210 1
10 • GEAR 6440-13220 1
11 • NUT, M10 T3002-13260 1
12 • PINION T3002-13310 1
13 • BEARING T3300-13531 1
14 • BEARING T3403-13530 1
15 • RING T3300-13330 1
16 • RING 04065-02412 1
17 • BOLT 01252-30510 1
18 • BOLT 3350-21320 1
19 • HOLDER (A) 6440-13242 1
20 • FITTING, grease 3199-13350 1
21 • WASHER 01641-20608 1
22 HANGER-ASSY 6420-17300 1
23 • HANGER-COMP 6420-17400 1
24 • • HANGER 9366-17110 1
25 • • CLAMP 9366-17120 1
26 • • SLEEVE 6420-17410 1
27 • SCREW 0263-90525 1
28 PLATE-NAME T3143-12511 1
29 PLATE 6425-12552 1
30 W-HANDLE KIT T3002-95000 1
31 • HANDLE-L-COMP T3040-14200 1
32 • HANDLE-R-COMP T3002-95400 1
33 • LEVER-ASSY 6234-14601 1
34 • • COVER-COMP
6234-14601020 1
35 • • SHAFT
6110-14410060 1
36 • • BUTTON
6110-14410090 1
37 • • SPRING
6110-14410080 1
38 • CORD(A) BLACK T3002-95710 1
39 • CORD(B) RED T3002-95720 1
40 • CABLE-COMP T3040-83100 1
41 • TUBE 5512-73220 1
42 • CLAMP 3260-14251 1
43 • SCREW 0260-00516 1
44 • BRACKET-ASSY 3583-14101 1
45 • • BRACKET 3583-14111 1
46 • • CAP-L 3583-14121 1
47 • • CAP-U 3257-14192 1
48 • • BOLT 01252-30522 2
49 • • BOLT 01252-30525 4
50 • PROTECTOR 4050-17110 5
Key# Description Part Number Q'ty
51 • BAND 3540-93120 1
52 GUARD ASS’Y 6489-24000 1
53 • GUARD 6489-24110 1
54 • PLATE COMP. 6489-24200 1
55 • • PLATE 6489-24210 1
56 • • BLADE 6489-24220 1
57 • • SCREW 0277-10412 1
58 • PLATE 6489-24120 1
59 • BOLT 01252-30516 4
60 • WASHER 01601-20513 4
61 STRAP-ASSY T3300-17100 1
62 TOOL-SET T3002-91000 1
63 • SOCKET T3002-91310 1
64 • WRENCH 09007-00425 1
65 • SPANNER 3540-91120 1
66 • BAR 3540-91110 1
67 GOGGLE T3002-91190 1
68 TAP. HEAD 4" PT104 1
69 • CASE 6460-15113 1
70 • CORD HOLDER 6460-15142 1
71 • COVER 6460-15131 1
72 • SPRING 6041-99162 1
73 • TRIMMER LINE 6460-15180 1
74 • PLATE, large 3268-15150 1
75 • PLATE, small 3268-15170 1
76 HOLDER (B) 6019-13250 1
❲ 37 ❳
Fig.2 DRIVE UNIT BCZ2500SW (S/N 100001 and up)
OPTIONAL BLADE
