RedMax BCZ2600S - Page 35

101 9” 22-tooth SST229 1
102 9” 24-tooth SST249 1
103 8” 8-tooth SGB088 1
104 9” 8-tooth SGB089 1
105 8” 4-tooth SGB048 1
106 9” 4-tooth SGB049 1
107 GUARD ASS’Y 6489-24000 1
108 • GUARD 6489-24110 1
109 • PLATE COMP. 6489-24200 1
110 • • PLATE 6489-24210 1
111 • • BLADE 6489-24220 1
112 • • SCREW 0277-10412 1
113 • PLATE 6489-24120 1
114 • WASHER 01601-20513 1
115 • BOLT 01252-30516 1
116 J-HANDLE 6367-14200 1
117 BRACKET 3583-14101 1
118 COVER 3540-13283 1
Key# Description Part Number Q'ty
1A* PIPE-COMP, 1500xø24xT1.7 T3002-12101 1
1B
* PIPE-COMP, 1500xø24xT1.5 T3064-12100 1
2
SHAFT, 1536xø7, spline 7T 3520-12213 1
3 GEARCASE-ASSY T3002-13001 1
4• GEARCASE 6489-13110 1
5• BEARING T3300-13521 1
6• BEARING T3403-13510 1
7• RING 04065-02612 1
8• SEAL 3565-13130 1
9• SHAFT T3002-13210 1
10 • GEAR 6440-13220 1
11 • NUT, M10 T3002-13260 1
12 • PINION T3002-13310 1
13 • BEARING T3300-13531 1
14 • BEARING T3403-13530 1
15 • RING T3300-13330 1
16 • RING 04065-02412 1
17 • BOLT 01252-30510 1
18 • BOLT 3350-21320 1
19 • HOLDER (A) 6440-13242 1
20 • FITTING, grease 3199-13350 1
21 • WASHER 01641-20608 1
22 GRIP 3577-32141 1
23 LEVER-COMP T3002-12202 1
24 • LEVER 6110-14412 1
25 • COVER-COMP
6110-14410020 1
26 • SHAFT
6110-14410060 1
27 • BUTTON
6110-14410090 1
28 • SPRING
6110-14410080 1
29 • CORD (A) T3002-12220 1
30 • CORD (B) T3002-12230 1
31 TUBE T3002-12240 1
32 CABLE T3002-83100 1
33 HANGER-ASSY 6420-17300 1
34 • HANGER-COMP 6420-17400 1
35 • • HANGER 9366-17110 1
36 • • CLAMP 9366-17120 1
37 • • SLEEVE 6420-17410 1
38 • SCREW 0263-90525 1
39A
* LABEL NAME & CAUTION 848B5090R1 1
39B
* LABEL NAME & CAUTION 848B5290R1 1
41 HANDLE-ASSY T3339-14000 1
42 • HANDLE T3195-14102 1
43 • SCREW 0263-90530 4
45 GUARD-ASSY T3002-24001 1
46 • GUARD COMP T3002-24101 1
47 • • BLADE T3002-24121 1
48 • • SCREW 0263-90516 1
Key# Description Part Number Q'ty
49 • • NUT 3320-15310 1
50 • PLATE 6489-24120 1
51 • BOLT 01252-30514 4
52 STRAP-ASSY 848B503610 1
53 TOOL-SET T3002-91000 1
54 • SOCKET T3002-91310 1
55 • WRENCH 09007-00425 1
56 • SPANNER 3540-91120 1
57 • BAR 3540-91110 1
58 GOGGLE T3002-91190 1
59 TAP HEAD COMP. PT104 Plus 1
60 • CASE T3189-15112 1
61 • EYELET T3189-15191 2
62 • COVER T3189-15132 1
63 • CORD HOLDER T3189-15142 1
64 • SPRING T3189-15160 1
65 • CORD T3189-15180 1
66 HOLDER (B) 6019-13250 1
 35 
BCZ2600S (S/N 300001 and up)
Fig.1 DRIVE UNIT BCZ2600SU (S/N 300001 and up)
OPTIONAL BLADE & ACCESSORIES
* 1A, 39A for BCZ2600S
1B, 39B for BCZ2600SU
