RedMax BCZ2610S - Optional Blade Usage

42
12. Optional blade usage
English
OPT2
(1)
OPT1
Change to the debris guard which is suitable for the
metal blade. (OPT1)
TIGHTENING TORQUE :
26~43.5 in-lbs
(2.94~4.9 N.m.)
(1) Guard : T3246-24110
Change the loop handle to the J-handle for safe
operation. (OPT2)
(1) Bracket : 3583-14101
(2) J-handle : 6367-14200
IMPORTANT
IMPORTANT
