Fig.2 ENGINE UNIT BCZ2610S/BCZ2610S-CA (S/N 70050101 and up)
57
Key# Description Part Number Q'ty
1 CYLINDER 848-F3R-12A2 1
2 GASKET, base 848-F3R-12B0 1
3 BOLT, M5x22 4820-12130 2
4 INSULATOR 848-F40-14A0 1
5 GASKET, insulator 848-F40-14B0 1
6 GASKET, carburetor T1590-13130 1
7 7, SCREW,M3x6 848-853-0600 2
8 REEDVALVE (S) ASSY 848-F3R-1601 1
9• TUBE 848-8F4-0550 1
10 • PUMP ASSY 848-F40-8800 1
11 • REEDVALVE 848-F3R-16C0 1
12 • STOPPER 4810-16130 1
13 • SCREW, M3x8 4810-16170 1
14 PIRE AIR (S) 848-F3R-16E0 1
15 REEDVALVE (F) ASSY 848-F3R-1611 1
16 • REEDVALVE 848-F3R-16C0 1
17 • STOPPER 4810-16130 1
18 • SCREW, M3x8 4810-16170 1
19 PIPE AIR (F) 848-F3R-16F0 1
20 GASKET, valve 848-F3R-16H0 2
21 SCREW 4810-16180 6
22 CRANKCASE COMP. 4810-21101 1
23 • PIN 2629-21130 3
24 GASKET 4810-21140 1
25 BEARING 06030-06001 2
26 SEAL 4810-21210 1
27 SEAL 1850-21220 1
28 SNAP RING 04065-02812 1
29 BOLT, M5x30 4820-21310 3
32 PISTON 848-F40-41A0 1
33 RING 848-8C3-4101 2
34 PIN 848-8B8-2800 1
35 RING 1260-41320 2
36 BEARING T1551-41410 1
37 WASHER 848-873-8002 2
38 CRANKSHAFT COMP. 848-F3R-4200 1
39 NUT 1650-43230 1
40 KEY 1000-43240 1
41 ROTOR 4810-71110 1
42 COIL ASSY T1512-71200 1
43 • CORD T1512-71220 1
44 • CAP 2616-71320 1
45 SPACER 1260-71261 2
46 BOLT, M4x22 4820-72150 2
47 CARBURETOR ASSY 848-F40-8100 1
48 • REBUILD KIT 848-F60-0630 1
49 • • BODY ASSY 1850-81450 1
50 • • GASKET KIT 4810-06021 1
51 • BODY 848-F40-81G0 1
52 • COVER 1850-81520 1
53 • PUMP 1751-81510 1
54 • RING 1751-81130 1
55 • SWIVEL 1881-81140 1
56 • SCREW 1752-81110 2
57 • BRACKET 5500-81120 1
58 • NUT 1751-81180 1
59 • SCREW 1918-81170 1
60 • SCREW 1850-81530 4
61 • WASHER 5500-81160 1
76 SCREW, M5x60 4820-82310 2
77 MUFFLER ASSY 848-F40-1510 1
79 • ARRESTER 4810-15140 1
Key# Description Part Number Q'ty
80 BOLT, M5x50 4820-15310 2
81 GASKET 848-F3R-15C0 1
82 PLATE, muffler 848-F3R-15D0 1
83 COVER ASSY 848-F30-5303 1
84 • COVER COMP. 4810-31102 1
85 • • COVER, fan 4810-31111 1
86 • • DRUM 848-F30-51A1 1
87 • • SNAPRING 04065-02812 1
88 • • BEARING T1701-31150 1
89 • • SNAP RING 04064-01210 1
90 • BRACKET (A) 6470-31211 1
91 • BRACKET (B) 6470-31221 1
92 • CUSHION 6470-31230 1
93 • BOLT, M5x30 4820-21310 2
94 • BOLT, M5x14 T1501-32120 1
95 SCREW, M5x16 4820-32120 5
96 COVER, engine 848-F3R-31A0 1
97 PLATE 848-F3R-12G0 1
98 SCREW, M5x10 4820-12350 2
99 SHOE 4820-51110 2
100 SPRING 4820-51220 1
101 SCREW 1140-51250 2
102 WASHER 1140-51230 2
103 WASHER 1140-51242 2
104 CAP 848-F30-71C2 1
105 SPRING 1900-72120 1
106 CORD 4810-71240 1
107 CORD, earth 4810-71250 1
108 TUBE T1512-71320 1
109 PLUG, NGK CMR7H 3699-91867 1
110 GROMMET 4810-72120 1
111 RECOIL ASSY 4810-75100 1
112 • REEL 4500-75120 1
113 • SCREW 4500-75150 1
114 • SPRING, spiral 1850-75130 1
115 • COLLAR 4500-75180 1
116 • ARM 4500-75190 1
117 • ROPE 4810-75160 1
118 • KNOB 3330-75421 1
119 • PLATE, stopper 4810-75170 1
120 PULLEY 4500-75210 1
121 SCREW, M5x16 T1501-32120 2
122 BODY ASSY 4810-82100 1
123 • PLATE, choke 4810-82130 1
124 • LEVER, choke 5500-82140 1
125 • SCREW 2630-33610 1
126 ELEMENT 4810-82170 1
128 COVER ASSY 848-F40-832 1
129 • KNOB 5500-82221 1
130a TANK ASSY 848-F34-8501 1
130b TANK ASSY (CA Only) 848-F43-8501 1
131 • CAP ASSY T1015-85202 1
132 • • HOLDER ASSY 4500-85300 1
133 • • PACKING 4500-85220 1
134 • • FILTER 5601-85260 1
135 • • STOPPER 4820-85260 1
136 • PIPE COMP. 4810-85300 1
137 • FLTER ASSY 3302-85400 1
138 • CLIP 1260-85460 1
139 SCREW, M5x16 4820-85510 3
140 LABEL, recoil 848-F40-90D0 1
141 LABEL, cover 848-F60-90B0 1
142 GUARD T1506-31910 1
143 BOLT, N5x22 4820-12130 2
144 CLIP 1950-86120 1
145 LABEL 4810-82230 1
