P/L-3
BCZ2650S/T/SS
Key# Part Number Description Q'ty
1 848-J8S-5820 PIPE COMP. 1
2 T3400-12130 • SEAL 1
3 3520-12213 SHAFT 1
4 848-JC0-6100 GEARCASE ASSY 1
5 6440-13122 • GEARCASE 1
6 04065-02612 • SNAP RING 1
7 3565-13130 • SEAL 1
8 T3002-13260 • NUT 1
9 848-JC0-61D0 • PINION 1
10 T3300-13531 • BEARING 1
11 T3403- 13530 • BEARING (0600000609) 1
12 T3300-13330 • SNAP RING 1
13 04065-02412 • RING (0243224120) 1
14 T4950-52500 • BOLT TORX, 5x25 1
15 6440-13242 • HOLDER (A) 1
16 3199-13350 • FITTING (2087061640) 1
17 01641-20608 • WASHER 1
18 T4950-51200 • BOLT TORX, 5x12 1
20 848-8R4-0600 GRIP ASSY 1
21 848-BRA-0391 • BODY-R 1
22 848-8RB-0391 • BODY-L 1
23 848-8RC-0600 • LEVER, THROTTLE 1
24 848-8RJ-0600 • SPRING, THROTTLE 1
25 848-8RD-0600 • LEVER, SAFETY 1
26 848-JL2-33F3 • SPRING 1
27 848-8RE-0600 • LEVER, JOINT 1
28 T4506-52110 • SWITCH 1
29 848-824-1600 • SCREW 4
30 848-8P4-0550 • CABLE COMP. 1
31 848-8M1-0820 • CORD COMP. 2
32 T3003-14510 • TUBE 1
33 848-8RH-0421 • BAND 2
35 4820-13180 • BOLT 2
36 848-860-5000 • NUT 2
42 T3300-17202 HANGER COMP. 1
43 848-805-2000 SCREW TORX, 5x20 1
44 848-JR7-90R0 NAME PLATE 1
45 T3195-14002 HANDLE ASSY 1
46 T4960-53030 • SCREW TORX, 5x30 4
47 T3245-24100 GUARD COMP. 1
48 T3002-24121 • BLADE 1
49 T4960-51431 • SCREW TORX, 5x14 1
50 3320-15310 • NUT 1
51 848-JC0-66C1 BRACKET 1
52 T4950-63000 BOLT TORX, 6x30 2
Key# Part Number Description Q'ty
54 848-A56-92C0 GOGGLE 1
55 PT104 Plus TAP HEAD COMP. 1
56 T3189-15112 • CASE 1
57 T3189-15191 • EYELET 2
58 T3189-15132 • COVER 1
59 T3189-15142 • CORD HOLDER 1
60 T3189-15160 • SPRING 1
61 T3189-15180 • CORD 1
62 848-8X1-0040 CAUTION LABEL 1
101 X375000948 BLADE KIT (PRODUCT)
102 T3246-24110 • GUARD 1
103 6367-14200 • J-HANDLE 1
104 848-JC1-3230 • BRACKET ASSY 1
105 3540-13283 • COVER 1
106 SST229 9” 22-tooth 1
107 SST249 9” 24-tooth 1
108 SGB088 8” 8-tooth 1
109 SGB089 9” 8-tooth 1
110 SGB048 8” 4-tooth 1
111 SGB049 9” 4-tooth 1
112 848-B50-3610 STRAP ASSY 1
113 6019-13250 HOLDER (B) 1
Fig.1 DRIVE UNIT BCZ2650S (S/N 90200101 and up)
OPTIONAL BLADE & ACCESSORIES
14. Parts list
