Key# Part Number Description Q'ty
1 848-F3R-12A2 CYLINDER 1
2 848-F3R-12B0 GASKET, base 1
3 4820-12130 BOLT, M5x22 2
4 848-F40-14A0 INSULATOR 1
5 848-F40-14B0 GASKET, insulator 1
6 T1590-13130 GASKET, carburetor 1
7 848-853-0600 SCREW,M3x6 2
8 848-8F4-0550 TUBE 1
9 848-F40-8801 PUMP ASSY 1
10 848-F3R-1601 REEDVALVE (S) ASSY 1
11 848-F3R-16C0 • REEDVALVE 1
12 4810-16130 • STOPPER 1
13 4810-16170 • SCREW, M3x8 1
14 848-F3R-16E0 PIRE AIR (S) 1
15 848-F3R-1611 REEDVALVE (F) ASSY 1
16 848-F3R-16C0 • REEDVALVE 1
17 4810-16130 • STOPPER 1
18 4810-16170 • SCREW, M3x8 1
19 848-F3R-16F0 PIPE AIR (F) 1
20 848-F3R-16H0 GASKET, valve 2
21 4810-16180 SCREW 6
22 4810-21101 CRANKCASE COMP. 1
23 2629-21130 • PIN 3
24 4810-21140 GASKET 1
25 T1802-21240 BEARING 2
26 4810-21210 SEAL 1
27 1850-21220 SEAL 1
28 04065-02812 SNAP RING 1
29 4820-21310 BOLT, M5x30 3
32 848-F40-41A0 PISTON 1
33 848-8C3-4101 RING 2
34 848-8B8-2800 PIN 1
35 1260-41320 RING 2
36 T1551-41410 BEARING 1
37 848-873-8002 WASHER 2
38 848-F3R-4200 CRANKSHAFT COMP. 1
39 1650-43230 NUT 1
40 1000-43240 KEY 1
41 4810-71110 ROTOR 1
42 T1512-71200 COIL ASSY 1
43 T1512-71220 • CORD 1
44 2616-71320 • CAP 1
45 1260-71261 SPACER 2
46 4820-72150 BOLT, M4x22 2
47 848-F4J-8100 CARBURETOR ASSY 1
48 848-F60-0630 • REBUILD KIT 1
49 1850-81450 • • BODY ASSY 1
50 4810-06021 • • GASKET KIT 1
51 848-F40-81G0 • BODY 1
52 1850-81520 • COVER 1
53 1751-81510 • PUMP 1
54 1751-81130 • RING 1
55 1881-81140 • SWIVEL 1
56 1752-81110 • SCREW 2
57 5500-81120 • BRACKET 1
58 1751-81180 • NUT 1
59 1918-81170 • SCREW 1
60 1850-81530 • SCREW 4
61 5500-81160 • WASHER 1
76 848-805-6000 SCREW, M5x60 2
77 848-F40-1510 MUFFLER ASSY 1
79 4810-15140 • ARRESTER 1
80 4820-15310 BOLT, M5x50 2
81 848-F3R-15C0 GASKET 1
Key# Part Number Description Q'ty
82 848-F3R-15D0 PLATE, muffler 1
83 848-F30-5303 COVER ASSY 1
84 4810-31102 • COVER COMP. 1
85 4810-31111 • • COVER, fan 1
86 848-F30-51A1 • • DRUM 1
87 04065-02812 • • SNAPRING 1
88 T1701-31150 • • BEARING 1
89 04064-01210 • • SNAP RING 1
90 6470-31211 • BRACKET (A) 1
91 6470-31221 • BRACKET (B) 1
92 6470-31230 • CUSHION 1
93 4820-21310 • BOLT, M5x30 2
94 T1501-32120 • BOLT, M5x14 1
95 4820-32120 SCREW, M5x16 3
96 848-F3R-31A0 COVER, engine 1
97 848-F3R-12G0 PLATE 1
98 4820-12350 SCREW, M5x10 2
99 4820-51100 SHOE COMP, 1
100 4820-51220 • SPRING 1
101 1140-51250 SCREW 2
102 1140-51230 WASHER 2
103 1140-51242 WASHER 2
104 848-F30-71C2 CAP 1
105 1900-72120 SPRING 1
106 4810-71240 CORD 1
107 4810-71250 CORD, earth 1
108 T1512-71320 TUBE 1
109 3699-91867 PLUG, NGK CMR7H 1
110 4810-72120 GROMMET 1
111 4810-75100 RECOIL ASSY 1
112 4500-75120 • REEL 1
113 4500-75150 • SCREW 1
114 1850-75130 • SPRING, spiral 1
115 4500-75180 • COLLAR 1
116 4500-75190 • ARM 1
117 4810-75160 • ROPE 1
118 3330-75421 • KNOB 1
119 4810-75170 • PLATE, stopper 1
120 4500-75210 PULLEY 1
121 T1501-32120 SCREW, M5x16 2
122 4820-12310 BOLT, N5x22 2
123 848-F4J-83A0 BODY ASSY 1
124 848-F70-83C0 • PLATE, choke 1
125 848-F70-83D0 • LEVER 1
126 T1108-82190 • SCREW 1
127 848-F70-83T0 ELEMENT 1
128 848-F70-8320 COVER ASSY 1
129 848-F70-83J0 • KNOB 1
130 848-F43-8503 TANK ASSY 1
131 T1015-85202 • CAP ASSY 1
132 4500-85300 • • HOLDER ASSY 1
133 4500-85220 • • PACKING 1
134 5601-85260 • • FILTER 1
135 4820-85260 • • STOPPER 1
136 4810-85300 • PIPE COMP. 1
137 3306-85400 • FLTER ASSY 1
138 1260-85460 • CLIP 1
139 4820-85510 SCREW, M5x16 3
140 848-F4J-90C0 LABEL, recoil 1
141 848-F4J-90D0 LABEL, emission 1
142 848-F40-85Z0 GUARD 1
143 4820-12130 BOLT, N5x22 2
144 1950-86120 CLIP 1
145 848-750-0401 LABEL 1
146 848-F70-83Y0 PLATE 1
P/L-7
BCZ2650S/T/SS
Fig.3 ENGINE UNIT BCZ2650S/T/SS (S/N 90200101 and up)
14. Parts list
