Fig.2 ENGINE GROUP (S/N 200101 and up)
Key# Part Number Description Q'ty
1 2750-12111 CYLINDER 1
2 2750-12210 GASKET, base 1
3 1850-12130 BOLT 4
4 1484-13161 INSULATOR 1
5 2750-13130 GASKET 1
6 1460-13132 GASKET 1
7 1484-13170 BOLT 2
8 2750-12510 COVER 1
9 2750-12520 BOLT 2
10 2756-15100 MUFFLER ASS’Y 1
11 1421-15120 • ARRESTER 1
12 2750-15210 GASKET 1
13 2750-15160 BOLT 2
14 2750-15170 BOLT 1
15 2750-21101 CRANKCASE COMP 1
16 2750-21140 GASKET 1
17 T4012-21240 BEARING 3
18 T4019-21210 OIL SEAL 1
19 T1108-21220 OIL SEAL 1
20 01252-30530 BOLT 4
21 04065-03515 SNAP RING 1
22 2750-21211 COVER 1
23 1565-72211 BOLT 1
24 2750-21510 BOLT 6
25 2750-41110 PISTON 1
26 3366-41210 RING 2
27 3366-41310 PISTON PIN 1
28 3350-41320 SNAP RING 2
29 1400-41410 BEARING 1
30 2616-41510 WASHER 2
31 2750-42000 CRANKSHAFT COMP 1
32 1300-42410 SHIM 0~1
33 1400-43230 NUT 2
34 1000-43240 KEY 1
35 2750-71111 ROTOR 1
36 2750-71200 COIL ASS’Y 1
37 3350-14150 BOLT 2
38 1900-72112 CAP 1
39 1900-72120 SPRING 1
40 5500-72130 GROMMET 1
41 5602-73110 SPARK PLUG (RCJ6Y) 1
42 2751-71220 CAP 1
43 2750-73200 CORD COMP 1
44 T4030-75100 RECOIL ASS’Y 1
45 1180-75221 • SPRING 1
46 T4030-75120 • REEL 1
Key# Part Number Description Q'ty
47 T4030-75140 • DOG 1
48 1861-75150 • WASHER 1
49 1483-75270 • SCREW 1
50 1487-75160 • RETAINER 1
51 1487-75170 • WASHER 1
52 1400-75160 • ROPE 1
53 1400-75170 • KNOB 1
54 1487-75211 PULLEY 1
55 3460-75510 BOLT 4
57 T4012-81000 CARBURETOR 1
58 T4012-82401 CASE ASS’Y 1
59 T4012-82421 • PLATE 1
60 T4012-82431 • LEVER 1
61 T4012-82441 • SCREW 1
62 T4012-82510 PLATE 1
63 0263-90550 SCREW 2
101 2750-05013 SHORT BLOCK
*Acc
102 2750-06010 GASKET KIT *Acc
103 2750-96100 PULLER ASS’Y *Acc
104 3350-96220 STOPPER *Acc
105 2750-96230 GUIDE *Acc
106 2750-96240 GAUGE *Acc
*Acc: Accessory, which is not included in standard package.
