EBZ4800/EBZ4800RH
Fig.2 ENGINE GROUP (S/N 100101 and up)
Key# Part Number Description Q'ty
1 T1108-12110 CYLINDER 1
2 T1108-12210 GASKET, BASE 1
3 4820-12130 BOLT 4
4 T1108-12310 PLATE 1
5 T4960-50810 SCREW 2
6 T1108-13160 INSULATOR 1
7 T4950-52030 BOLT 4
8 T1108-13120 GASKET, INSU 1
9 T1108-13130 GASKET, CARB 1
10 T1108-15110 MUFFLER 1
11 T1108-15120 ARRESTER 1
12 1410-86130 CLIP 1
13 T4950-67031 BOLT 2
14 T4950-61431 BOLT 1
15 T1108-15210 GASKET, MUFF 1
16 T1108-21100 CRANKCASE-C 1
17 T1108-21140 GASKET, CASE 1
18 T4012-21240 BEARING 2
19 T4019-21210 SEAL 1
20 T1108-21220 SEAL 1
21 04065-03515 SNAPRING 1
22 4820-21310 BOLT 4
23 2750-21211 COVER, MAG 1
24 4820-72150 BOLT 1
25 T1108-41110 PISTON 1
26 2670-41211 RING, PISTON 2
27 2880-41310 PIN 1
28 3350-41320 SNAPRING 2
29 1400-41410 BEARING 1
30 2616-41510 WASHER 2
31 T1108-42000 CRANKSHAFT-C 1
32 1300-42410 SHIM 1
33 1400-43230 NUT 2
34 1000-43240 KEY 1
35 T1108-71110 ROTOR 1
36 T1108-71200 COIL-A 1
37 T1108-72110 • CAP 1
38 T1108-72120 • SPRING 1
39 T1108-72130 • TUBE 1
40 5500-72130 • GROMMET 1
41 4820-72150 BOLT 2
42 T1108-71240 CORD COMP 1
43 T1108-73110
SPARK PLUG, NGK CMR7H
1
44 1487-75001 STARTER-A 1
45 1487-75101 • RECOIL-A 1
46 1180-75221 • • SPRING 1
Key# Part Number Description Q'ty
47 1487-75120 • • REEL 1
48 1487-75140 • • DOG 1
49 1861-75150 • • WASHER 1
50 1483-75270 • • SCREW 1
51 1487-75160 • • RETAINER 1
52 1487-75170 • • WASHER 1
53 1400-75160 • • ROPE 1
54 1400-75170 • • KNOB 1
55 1487-75211 • PULLEY 1
56 T4960-51431 SCREW 4
58 T1108-81000 CARBURETOR 1
59 T4950-56240 BOLT 2
60 T1108-82100 BODY-A 1
61 T1108-82130 • PLATE, CHOKE 1
62 T1108-82140 • LEVER 1
63 T1018-82190 • SCREW 1
64 T1108-82180 • O-RING 1
65 T1108-82150 PLATE 1
66 T1108-82300 PACKING-C 1
67 T1108-82310 • PACKING 1
68 T1108-82320 • SCREEN 1
69 T1108-82170 ELEMENT 1
70 T1108-82200 COVER-A 1
71 T1108-82220 • KNOB 2
72 T1108-82060 LABEL, CHOKE 1
73 T4950-64031 BOLT 6
74 6129-61210 BAND 1
101 T1108-05010 SHORT BLOCK
*Acc
102 T1108-06010 GASKET KIT
*Acc
103 2750-96100 PULLER
*Acc
104 4810-96220 STOPPER
*Acc
105 2750-96230 GUIDE
*Acc
106 2750-96240 GAUGE
*Acc
*Acc: Accessory, which is not included in standard package.
