25
EBZ5000/EBZ5000RH
Fig.1 BLOWER GROUP (S/N 300001 and up)
Key# Part Number Description Q'ty
1 T4017-31110 VOLUTE CASE 1
2 848-L36-55B0 VOLUTE COVER 1
3 T4970-52510 SCREW 10
4 T4970-52510 SCREW 3
5 T4030-31410 ELBOW 1
6 07000-02095 O-RING 1
7 T4960-57030 SCREW 2
8 3310-53331 NUT 2
9 T4017-31310 FUNNEL 1
10 848-8K4-0010 CLAMP 1
11 T4970-51410 SCREW 1
12 2750-31290 TUBE 1
13 T4017-31510 FAN 1
14 T4950-63031 BOLT 4
15 T4017-31610 ENGINE COVER 1
18 T4970-52510 SCREW 5
19 T4017-32100 FLAME COMP. 1
20 3490-21121 • RING 2
21 2756-32310 BAND (A) 2
22 T4017-32320 BAND (B) 2
24 T4017-21310 PAD 1
25 3495-21320 CLIP 5
26 T4017-32500 NET COMP. 1
27 1480-74710 CLIP 4
30 2750-32510 DAMPER, UPPER 1
31 2750-32520 WASHER 1
32 T4972-54010 SCREW 1
33 T4960-51631 SCREW 2
34 2750-32610 DAMPER, LOWER 2
35 2750-32620 NUT 2
36 T4017-85100 TANK ASSY 1
37 T1015-85202 • CAP-A 1
38 4500-85300 • • HOLDER ASSY 1
39 4500-85220 • • PACKING 1
40 5601-85260 • • FILTER 1
41 4820-85260 • • STOPPER 1
42 2750-85300 • PIPE COMP. 1
43 3302-85400 • FILTER 1
44 1260-85460 • CLIP 1
45 T4960-51231 SCREW 2
46 1950-86120 CLIP 1
47 2750-31911 LABEL, CAUTION 1
48 T4012-32610 LABEL, NET 1
50 848-L3B-90J0 LABEL, NOISE 1
51 T4030-51110 HOSE 1
52 2750-51201 SWIVEL JOINT 1
Key# Part Number Description Q'ty
53 6811-51211 PIPE 1
54 6811-51220 PIPE, END 1
56 T4030-51510 CLAMP 1
57 2756-51520 CLAMP 1
58 T4017-91000 TOOL SET 1
59 3540-91120 • SPANNER 1
60 T4017-91130 • SOCKET 1
