EBZ5100/EBZ5100RH
Fig.2 ENGINE GROUP (S/N 70100001 and up)
Key# Part Number Description Q'ty
1 848-HE0-12A1 CYLINDER 1
2 848-HE0-12B0 GASKET, BASE 1
3 4820-12130 BOLT TORX 4
4 T1108-12310 PLATE, CYL 1
5 T4960-50810 SCREW TORX 2
6 848-GC0-14A1 INSULATOR 1
7 848-815-2002 BOLT TORX 4
8 848-HE0-14B0 GASKET, INSU 1
9 848-HE0-14C0 GASKET, CARB 1
14 848-HE0-1510 MUFFLER ASSY 1
15 848-HE0-15B0 • ARRESTER 1
16 848-HE0-15U0 • DIFFUSER 1
17 T4950-40800 • BOLT 4
18 T4950-67031 BOLT TORX 2
19 T4950-61431 BOLT TORX 1
20 T1108-15210 GASKET, MUFFLER 1
21 T1108-21101 CRANKCASE COMP. 1
22 848-HE0-21D0 GASKET, CASE 1
23 T4012-21240 BEARING 2
24 T4019-21210 SEAL 1
25 T1108-21220 SEAL 1
26 04065-03515 SNAP RING 2
27 4820-21310 BOLT TORX 4
28 2750-21211 COVER 1
29 4820-72150 BOLT TORX 1
30 848-816-4500 BOLT TORX 6
31 848-HE0-41A0 PISTON 1
32 848-8C4-4200 RING 2
33 2880-41310 PIN 1
34 3350-41320 SNAP RING 2
35 1400-41410 BEARING 1
36 2616-41510 WASHER 2
37 848-HE0-4200 CRANKSHAFT COMP. 1
38 1400-43230 NUT 1
39 1000-43240 KEY 1
40 848-HE0-71A0 ROTOR 1
41 848-HE2-7120 COIL ASSY 1
42 2616-71320 • CAP 1
43 848-HE2-71D0 • CORD 1
44 848-HE0-71E0 • TUBE 1
45 T1108-72130 • TUBE 1
46 5500-72130 • GROMMET 1
47 5500-72120 • SPRING 1
48 T1108-72110 • CAP 1
49 4820-72150 BOLT TORX 2
Key# Part Number Description Q'ty
50 T1108-71240 CORD COMP. 1
51 3699-91867 SPARKPLUG 1
52 T4030-75100 RECOIL ASSY 1
53 1180-75221 • SPRING 1
54 T4030-75120 • REEL 1
55 T4030-75140 • DOG 1
56 1861-75150 • WASHER 1
57 848-G1K-75E0 • SCREW 1
58 1487-75160 • RETAINER 1
59 1487-75170 • WASHER 1
60 1400-75160 • ROPE 1
61 1400-75170 • KNOB 1
62 1487-75211 PULLEY 1
63 4820-32120 BOLT TORX 4
64 848-HE0-8100 CARBURETOR ASSY 1
65 T4950-56240 BOLT TORX 2
66 T1108-82100 BODY ASSY 1
67 T1108-82130 • PLATE, CHOKE 1
68 T1108-82140 • LEVER 1
69 T1108-82190 • SCREW 1
70 T1108-82180 • O-RING 1
71 T1108-82150 PLATE 1
72 T1108-82300 PACKING COMP. 1
73 T1108-82310 • PACKING 1
74 T1108-82320 • SCREEN 1
75 848-HE0-83F0 ELEMENT 1
76 848-HE2-8320 COVER ASSY 1
77 T1108-82220 • KNOB 2
78 4500-81910 COVER 1
80 848-HE0-1000 SHORT BLOCK Acc
81 848-HE0-0610 GASKET KIT Acc
82 2750-96100 PULLER ASSY Acc
83 4810-96220 STOPPER Acc
84 2750-96240 GAUGE Acc
87 T1108-82061 LABEL, CHOKE 1
Acc: Accessory, which is not included in standard package.
