EBZ8001/EBZ8001RH
Fig.2 ENGINE GROUP
Key# Part Number Description Q'ty
1 848-H00-12A2 CYLINDER 1
2 848-H00-12B1 GASKET, BASE 1
3 4820-12130 BOLT TORX 4
4 848-H00-12G0 PLATE, CYL 1
5 T4960-50810 SCREW TORX 2
6 848-H00-14A0 INSULATOR 1
7 848-815-2001 BOLT TORX 4
8 848-H00-14B2 GASKET, INSU 1
9 848-H00-14C1 GASKET, CARB 1
10 848-H00-12C0 COVER, TR-S 1
11 848-H00-12D0 COVER, TR-F 1
12 4820-72150 BOLT TORX 4
13 848-H00-12E1 GASKET TR 2
14 848-H10-1510 MUFFLER ASSY 1
15 848-H10-15B0 • ARRESTER 1
16 848-H10-15U0 • DIFFUSER 1
17 T4950-40800 • BOLT 4
18 848-816-7500 BOLT TORX 2
19 T4950-61431 BOLT TORX 1
20 848-H00-15C1 GASKET, MUFFLER 1
21 848-H00-2110 CRANKCASE COMP. 1
22 848-H00-21D1 GASKET, CASE 1
23 848-89G-4200 BEARING 2
24 848-8AG-2700 SEAL 1
25 848-8AG-4200 SEAL 1
26 04065-04218 SNAP RING 2
27 4820-21310 BOLT TORX 4
28 848-H00-21H0 COVER 1
29 4820-72150 BOLT TORX 1
30 848-816-4500 BOLT TORX 6
31 848-H00-41A1 PISTON 1
32 848-8C5-0200 RING 2
33 848-8BC-4500 PIN 1
34 848-8T3-1300 SNAP RING 2
35 848-88C-1600 BEARING 1
36 848-873-C000 WASHER 2
37 848-H00-4203 CRANKSHAFT COMP. 1
38 1400-43230 NUT 1
39 1000-43240 KEY 1
40 848-H10-71A0 ROTOR 1
41 848-H10-7121 COIL ASSY 1
42 T1108-72110 • CAP 1
43 T1108-72120 • SPRING 1
44 T1108-72130 • TUBE 1
45 5500-72130 • GROMMET 1
Key# Part Number Description Q'ty
46 4820-72150 BOLT TORX 2
47 T1108-71240 CORD COMP. 1
48 3699-91867 SPARKPLUG 1
49 848-H00-7512 RECOIL ASSY 1
50 848-H00-75C2 • REEL 1
51 848-H00-75B0 • SPRING 1
52 848-H00-75M1 • WASHER 1
53 848-H00-75L2 • SPRING FRICTION 1
54 848-H00-75K2 • PLATE FRICTION 1
55 848-H00-75W1 • WASHER 1
56 4500-75150 • SCREW 1
57 848-8S9-0000 • ROPE 1
58 848-H00-75J0 • KNOB 1
59 848-H00-75Z0 • KNOB CAP 1
60 848-H00-7521 PULLEY ASSY 1
61 4820-32120 BOLT TORX 4
62 848-H00-8000 CARBURETOR SET 1
63 848-H00-8100 • CARBURETOR ASSY 1
64 848-8M1-0550 • CORD 1
65 4820-82310 BOLT TORX 2
66 848-H01-8330 CUP ASSY 1
67 848-H01-83C0 • PLATE, CHOKE 1
68 848-H01-83D0 • LEVER 1
69 848-854-1600 • SCREW 1
70 848-870-4000 • WASHER 1
71 848-H00-84A0 • SPRING 1
72 07000-11007 • O-RING 1
73 848-H00-8341 COVER ASSY 1
74 848-H00-83K1 • SCREEN 1
75 1491-82360 • SCREW 2
76 T4970-52510 SCREW TORX 3
77 848-H00-83M1 GASKET, CUP 1
78 4500-81910 COVER 1
80 848-H00-1000 SHORT BLOCK Acc
81 848-H00-0610 GASKET KIT Acc
82 2750-96100 PULLER ASSY Acc
83 4810-96220 STOPPER Acc
84 2750-96240 GAUGE Acc
85 848-H00-2100
CASE ASSY (with BAG) Acc
86 848-8W0-0020 PULLER Acc
87 T1108-82061 LABEL, CHOKE 1
Acc: Accessory, which is not included in standard package.
47
(EBZ8001 : S/N 61206884 and up)
(EBZ8001RH : S/N 61201408 and up)
