23
❳
Fig.1 POWER UNIT (S/N 002191 and up)
G310TS
1 2870-12111 CYLINDER 1
2 2633-15100 MUFFLER ASS’Y 1
3 2633-15110 • BASE 1
4 2633-15120 • COVER 1
5 2630-15130 • BUFFLE 1
6 2633-15150 • SPARK ARRESTER 1
7 2633-15160 COVER 1
8 2630-15210 GASKET 1
9 3330-15220 BOLT 2
10 2870-21111 CRANKCASE 1
11 01252-30530 BOLT 4
12 2870-22102 VALVE ASS’Y 1
13 2870-22211 GASKET 1
14 3330-141211 GASKET 1
15 2875-31103 ENGINE CASE COMP. 1
16 2870-31510 VALVE 1
17 2831-31202 FUEL PIPE ASS’Y 1
18 1492-85410 • PIPE 1
19 1850-85300 • FILTER ASS’Y 1
20 1260-85460 • CLIP 2
21 3350-34320 • ELBOW 1
22 2631-31250 • GROMMET 1
23 3317-86100 • BREATHER ASS’Y 1
24 2630-31301 OIL PIPE ASS’Y 1
25 1492-85410 • PIPE 1
26 2630-31321 • GROMMET 1
27 2630-31330 • JOINT 1
28 2630-31350 • FILTER 1
29 1492-85410 PIPE 1
30 3370-31210 PIN 1
31 2630-31510 VALVE ASS'Y 1
32 2870-22251 SEAL 1
33 2630-31650 CAP 1
34 2870-31750 SCREW 4
35 2841-31800 CAP ASS'Y 2
36 2630-31820 • GASKET 2
37 ––––––––– STOPPER
38 2630-31913 COVER 2
39 2630-31950 SCREW 2
40 2632-32103 FRONT HANDLE ASS'Y 1
41 2630-32121 • JOINT (A) 1
42 2630-32151 • STOPPER 1
43 2630-32170 • SCREW 1
44 2630-32170 SCREW 1
45 2630-32610 SCREW 1
46 2630-33103 REAR HANDLE COMP. 1
47 3330-33250 • STOPPER 2
48 3310-33262 • SPRING 1
49 3310-33271 • KNOB 1
50 2630-33312 THROTTLE LEVER 1
51 3356-33321 SPRING 1
52 04025-00524 PIN 1
53 3356-33352 ARM 1
Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE
54 2630-33410 COVER 1
55 2630-31950 SCREW 1
56 2630-33511 JOINT (B) 3
57 2640-33530 BOLT 3
58 2630-33610 SCREW 6
59 2870-41111 PISTON 1
60 3319-41210 RING 1
61 3304-41310 PIN 1
62 3310-41320 SNAP RING 2
63 3310-41410 BEARING 1
64 1650-41510 WASHER 2
65 2870-42002 CRANKSHAFT COMP. 1
66 06030-06201 BEARING 2
67 2630-43150 OIL SEAL 1
68 04065-03212 SNAP RING 1
69 2169-21210 OIL SEAL 1
70 1650-43230 NUT 1
71 2872-51111 CLUTCH DRUM 1
72 3310-51310 BEARING 1
73 2870-51200 CLUTCH ASS'Y 1
74 ––––––––– • SHOE
75 3317-51240 • BOSS (B) 1
76 2870-51230 • SPRING 1
77 2630-98610 • BOSS (A) 1
78 2872-54004 CHAIN BRAKE ASS'Y 1
79 2872-53115 • COVER 1
80 2872-54112 • GUARD 1
81 2872-54120 • SPRING 1
82 0263-80530 • SCREW 1
83 2872-54140 • SPACER 1
84 2850-54211 • SPACER 1
85 2872-54220 • WEIGHT 1
86 2872-54230 • SPRING 1
87 2851-54270 • SPRING 1
88 01641-20508 • WASHER 1
89 3310-53331 • NUT (B) 1
90 2851-54301 • LEVER COMP. 1
91 2851-54350 • PIN 1
92 2670-54410 • ARM 1
93 2872-54510 • BAND 1
94 3356-24140 • PIN 1
95 2670-54610 • SPRING 1
96 2872-54623 • COVER 1
97 2630-33610 • SCREW 3
98 2831-54120 LABEL 1
99 2648-54350 LABEL 1
100 3350-53410 NUT 1
101 2870-53310 PLATE 1
102 2630-53330 SCREW 1
103 3310-53320 NUT (A) 1
104 2630-53412 CATCHER 1
105 2630-32170 SCREW 1
106 2630-55103 OIL PUMP ASS'Y 1
Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE
107 2630-55160 • GEAR 1
108 0261-00416 SCREW 2
109 2630-55211 PLATE 1
110 2630-55251 SEAL 1
111 2630-55312 COVER 1
112 2630-31950 SCREW 2
113 2634-71111 MODULE 1
114 2631-71203 ROTOR ASS'Y 1
115 2630-71221 • PAWL 2
116 2630-71231 • SPRING 2
117 0308-00040 • SNAP RING 2
118 5600-72150 SPACER 2
119 3310-72150 BOLT 2
120 5602-73110 SPARK PLUG (RCJ8Y) 1
121 5500-72110 CAP 1
122 1900-72120 SPRING 1
123 2630-72211 TUBE 1
124 2634-72500 SWITCH ASS'Y 1
125 2630-72610 LEAD 1
126 2870-75002 STARTER ASS'Y 1
127 2870-75101 • CASE COMP. 1
128 3330-75121 •• GUIDE 1
129 2630-75213 • REEL 1
130 1260-75151 • ROPE 1
131 3330-75421 • KNOB 1
132 3330-75201 • HOLDER COMP. 1
133 2630-75410 • WASHER 1
134 2630-75510 • SCREW 1
135 2870-75610 • COVER 1
136 2630-33610 • SCREW 1
137 2630-31950 SCREW 4
138 2875-75130 LABEL 1
139 2875-81001 CARBURETOR ASS'Y 1
140 3310-82110 WASHER 1
141 2875-82120 CHOKE PLATE 1
142 2630-82140 SCREW 2
143 2630-82151 THROTTLE ROD 1
144 2630-82160 GROMMET 1
145 2630-82210 GROMMET (A) 1
146 2875-82221 GROMMET (B) 1
147 2630-82311 CHOKE ROD 1
148 3320-33310 GROMMET 1
149 2631-82550 CAP 1
150 2630-98500 COVER ASS'Y 1
151 2630-83120 • KNOB 1
152 0308-00040 • SNAP RING 1
153 2630-83511 CLEANER 1
154 2870-83610 ELEMENT 1
155 2875-31411 LABEL 1
156 0304-02040 RIVET 4
Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE
To Next Page
