Fig.2 CARBBURETOR COMPONENTS & ACCESSORIES (S/N 002191 and up)
G310TS
Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE
1 2875-81001
CARBURETOR ASS'Y
2 3306-81380 SCREEN 1
3 2875-81120 PUMP COVER 1
4 3310-81130 SCREW 1
5 3356-81310 VALVE, inlet 1
6 3310-81280 COVER 1
7 2867-81270 SPRING 1
8 3310-81240 SCREW 1
9 3310-81250 PIN 1
10 3310-81230 LEVER 1
11 1480-81420 PLUG 1
12 3350-81380 SPRING 1
13 2630-81330 SCREW 1
14 3310-81360 SCREW 2
15 3310-81341 VALVE 1
16 2670-81410 SPRING 1
17 2875-81370 SHAFT ASS'Y 1
18 2630-81440 LEVER 1
19 1148-81390 RING 1
20 3310-81351 SCREW 4
21 2850-06020 GASKET KIT 1
22 G0011 BAR 14” (350mm) 1
23 91SG-52X CHAIN 91SG-52E 1
24 3617-97110 PROTECTOR 1
25 3320-91140 WRENCH 1
26 3320-96410 STOPPER 1 OP
27 3330-97310 GUAGE 1 OP
28 2670-96210 WRENCH 1 OP
29 2670-96240 WRENCH 1 OP
30 2670-96410
1OP
31 3304-97611
1OP
WRENCH TORX (T20 x T25 x T25 )
WRENCH TORX (B3 x B4 x B5)
