G5300 (810)
Key# PART NUMBER DESCRIPTION
QTY/
UNIT
1 503 86 37-05 FUEL TANK ASSY 1
2 537 35 95-01 •TANK VENT ASSY 1
3 503 85 44-02 •THROTTLE LOCKOUT 1
4 503 99 86-01 •RECOIL SPRING 1
5 503 85 45-02 •THROTTLE TRIGGER 1
6 720 18 25-20 •PIN 1
7 544 32 50-02 FUEL HOSE 1
8 503 44 32-01 FILTER 1
9 503 21 88-76 SCREW 2
10 503 85 41-01 ANTIVIBRATION ELEMENT 2
11 544 32 49-20 FUEL HOSE 1
12 537 21 52-01 TANK CAP ASSY 1
13 503 57 89-01 •HOLDER 1
14 537 21 50-01 •SEALING 1
Key# PART NUMBER DESCRIPTION
QTY/
UNIT
1 503 21 88-76 SCREW 3
2 537 30 17-03 HANDLE 1
3 503 92 24-02 SPACER 1
4 503 89 83-01 ANTIVIBRATION ELEMENT 1
5 503 21 88-72 SCREW 2
Key# PART NUMBER DESCRIPTION
QTY/
UNIT
1 521 89 39-01 HAND GUARD ASSY 1
2 537 15 27-01 •HEAT PROTECTOR 1
3 503 92 95-01 WEAR WASHER 1
4 503 89 30-03 SCREW 2
5 537 02 99-01 WEAR PROTECTION 1
6 505 15 59-02 CHAIN BRAKE ASSY 1
7 503 89 29-01 •PIN KNEE-JOINT 1
8 503 21 70-10 •SCREW CCRPANT 1
9 503 89 08-02 •KNEE JOINT ASSY 1
10 503 46 59-01 •BRAKE SPRING 1
11 735 31 08-20 •E-CLIP 1
12 537 04 30-01 •BRAKE BAND ASSY 1
13 503 85 52-01 •GUIDE BUSHING 1
14 503 21 70-72 •SCREW CCRPANT 5
15 537 10 80-02 •CAP 1
16 537 08 90-01 •WEAR PROTECTION 1
17 503 85 66-01 •COVER PLATE 1
18 510 10 07-02 •LABEL 1
19 503 22 00-01 •NUT FLANGE 2
B
C
A
Key# PART NUMBER DESCRIPTION
QTY/
UNIT
1 503 89 06-01 AIR CONDUCTOR 1
2 505 24 76-02 STARTER ASSY 1
3 505 30 51-25 •STARTER CORD 1
4 503 21 77-16 •SCREW 1
5 503 21 28-10 •SCREW CCRPANT 2
6 537 09 25-01 •STARTER PULLEY 1
7 537 09 31-01 •SPRING CASSETTE ASSY 1
8 544 37 65-01 •STARTER HANDLE 1
9 505 25 97-01 •STARTER HOUSING 1
10 544 08 03-01 •SCREW 4
11 510 10 06-02 LABEL 1
Key# PART NUMBER DESCRIPTION
QTY/
UNIT
1 521 88 68-01 CYLINDER COVER ASSY 1
2 501 63 97-01 •COVER 1
3 503 84 59-01 •HEAT PROTECTOR 1
4 522 51 14-01 •LABEL 1
Key# PART NUMBER DESCRIPTION
QTY/
UNIT
1 503 21 74-12 SCREW 3
2 537 40 56-01 CHAIN GUIDE PLATE 1
3 537 14 65-01 BELLOWS 1
4 503 86 93-01 CARBURETTOR MOUNTING 2
5 503 21 75-12 SCREW 4
6 544 36 07-03 CARBURETTOR AREA BASE 1
7 537 17 19-07 CRANKCASE ASSY 1
8 503 20 07-76 •SCREW 3
9
537 04 03-01
•VALVE 1
10 721 12 07-30 •PIN 1
11 503 20 08-32 •SCREW IHSCM 6
12 503 21 51-01 •SCREW 2
13 503 86 92-01 •LATERAL SUPPORT 2
14 503 90 56-01 •GUIDE BUSHING 1
15 503 87 54-01 •BAR BOLT 2
16
503 90 56-01
•GUIDE BUSHING 1
17 503 20 25-16 SCREW IHSCM 2
18 503 43 65-01 POSITION SPRING 1
19 503 89 24-01 LOCK 1
20
503 93 04-01
BUMPER 1
21 503 90 59-01 SPIKE 1
22 537 07 12-01 CHAIN TENSIONER 1
23 503 88 63-01 CHAIN CATCHER PIN 1
24 544 33 10-01 HOSE 1
25 504 01 09-01 LINING 1
26 504 07 15-05 BRACKET 1
27
503 93 66-01
PRIMER HOUSING 1
28 544 44 97-01 SCREW 1
29 503 89 47-04 SNAP 3
30 503 88 86-01 AIR NOZZLE 1
31 503 21 39-01 SCREW 3
32 537 28 15-02 TANK CAP ASSY 1
33 503 57 89-01 •HOLDER 1
34
501 62 68-01
•GASKET 1
A 503 94 28-02 GASKET KIT 1
D
E
F
To Next Page
