25
G621AVS
Q'TY
Key# PART NUMBER DESCRIPTION NOTE
/UNIT
Fig.A-1 POWER UNIT (1)
2 3356-12141 Grommet 1
3 848-C90-14B3 Gasket 1
4 2618-14120 Insulator 1
5 848-C90-14C2 Gasket 1
6 2616-14211 Gasket 1
7 3310-12281 Bolt 4
8 848-C90-2104 Crankcase assy 1
9 848-C90-2112 • Crankcase comp. 1
10 04065-03515 • Snap ring 1
11 T4012-21240 • Bearing 2
12 2616-21250 • Ring 2
13 3350-21210 • Seal 1
14 T1108-21220 • Seal 1
15 2616-21230 • Stud 2
16 3350-21250 • Pin 1
17 3356-21270 • Pin 2
18 848-C90-21D2 • Gasket 1
19 3310-12281 Bolt 6
20 3356-23100 Oil pipe comp. 1
21 3356-23110 • Pipe 1
22 07000-11008 • O-ring 1
23 3310-57312 • Pipe 1
24 3310-57412 • Weight 1
25 3310-57511 • Clip 2
26 3356-23211 Pipe 1
27 848-C92-54A1 Guard 1
28 2670-14320 Screw 1
29 3356-24412 Cover 1
30 0263-60514 Screw 2
31 3350-25111 Screw 1
32 3350-25121 Stopper 1
33 3320-21191 Nut (A) 1
34 01641-20508 Washer 1
35 2616-25211 Catcher 1
36 2616-25230 Screw 1
37 3330-23121 Valve 1
38 3350-26220 Seal 1
39 3350-26230 Clip 1
40 3350-34210 Lever 1
41 3356-34221 Spring 1
42 2616-34230 Pin 1
43 3356-34301 Fuel pipe assy 1
44 3356-34310 • Pipe 1
45 3356-34320 • Grommet 1
46 1260-85460 • Clip 1
47 3302-85400 • Filter assy 1
48 3350-34501 Breather assy 1
49 3317-86100 • Breather 1
50 3350-34540 • Pipe 1
51 1260-85460 • Clip 1
52 2616-35112 Front damper 2
53 3356-35121 Cap 2
54 2616-35151 Rear damper (R) 1
55 2616-35132 Rear damper (L) 1
56 2616-35141 Rear damper (B) 1
57 1490-32120 Screw 1
58 2856-35180 Cap 1
59 0262-10514 Screw 2
60 3320-14140 Washer 2
61 2616-25320 Screw 2
62 2616-35170 Bolt 2
Q'TY
Key# PART NUMBER DESCRIPTION NOTE
/UNIT
63 2618-41112 Piston 1
64 2618-41210 Ring 2
65 3366-41310 Pin 1
66 3350-41320 Ring 2
67 1400-41410 Bearing 1
68 2616-41510 Washer 2
69 2616-42007 Crankshaft comp. 1
70 1300-42410 Shim 0-2 OP
71 1000-43240 Key 1
72 0290-21025 Washer 1
73 1300-43231 Nut 1
74 2616-51202 Clutch assy 1
75 2616-51210 • Plate 1
76 3350-51231 • Spring 1
77 3320-41410 Bearing 1
78 3350-51320 Washer 1
79 3310-43220 Nut 1
80 848-C90-6703 Oil pump assy 1
81 848-C90-6713 • Body 1
82 3356-55120 • Worm 1
83 3356-55310 Gasket 1
84 0263-90520 Screw 3
85 3356-55450 Grommet 1
86 3356-55511 Shaft 1
87 2618-75004 Starter assy 1
88 2618-75103 • Case comp. 1
89 2616-75120 • • Guide 1
90 3350-75213 • Reel 1
91 3356-75302 • Spring comp. 1
92 3356-75410 • Rope 1
93 3350-75420 • Knob 1
94 3310-75431 • Washer 1
95 3320-75350 • Washer 1
96 1490-32120 • Screw 1
97 2630-82550 • Screw 2
98 3366-75612 Cover 1
99 848-C90-75Z1 Screw 1
100 2616-75720 Screw 3
101 3356-82114 Manifold 1
103 01601-20513 Washer 2
104 01641-20508 Washer 2
106 2616-82310 Rod 1
107 2616-82410 Rod 1
108 848-C91-1510 Muffler assy 1
109 3359-15112 • Muffler 1
110 3357-15120 • Spark arrester 1
111 0263-20408 • Screw 1
112 848-C91-1520 • Cover set 1
114 01640-20610 • • Washer 2
115 3356-15210 Gasket 1
116 3356-15220 Bolt 2
117 3356-15230 Nut 2
118 848-C90-1260 Cylinder set 1
119 848-C90-12A7 • Cylinder 1
120 848-815-8500 • Bolt 2
To Next Page
