GZ400
Fig.1 POWER UNIT (S/N 0612000001 and up)
Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE Key# PART NUMBER DESCRIPTION
Q'TY
/UNIT
NOTE
1 848-C50-1211 CYLINDER ASSY 1
2 848-C50-12C1 • TR COVER MAG 1
3 848-C50-12D1 • TR COVER PTO 1
4 848-C50-12E1 • GASKET 2
5 2670-25430 • SCREW 6
6 848-C50-1403 INSULATOR ASSY 1
7 848-C50-16F2 • SEAL 1
8 848-C50-14B1 GASKET 1
10 2850-14212 GASKET, cyl 1
11 4820-13180 BOLT 4
15 848-C40-2102 CASE ASSY 1
–• PIN 3
17 848-89C-3200 BEARING 2
18 04065-03212 SNAP RING 1
19 2169-21210 SEAL 1
20 848-8AC-3210 SEAL 1
21 2616-21230 STAD 2
22 T2100-21310 GASKET 1
23 4820-21310 BOLT 4
35 848-C50-41A1 PISTON 1
36 2660-41211 RING 2
37 T2128-41310 PIN 1
38 1300-41320 RING 2
39 T2100-41410 BEARING 1
40 2850-41510 WASHER 2
41 T2128-42000 SHAFT COMP. 1
