RedMax HB2300 - Page 15

HB2300
Fig.1 ENGINE GROUP
Key# Part Number Description Q'ty
1 5580-12110 Cylinder 1
2 5500-12211 Gasket, base 1
3 1850-12130 Bolt, M5x22 2
4 5500-13162 Insulator 1
5 5500-13120 Gasket, Insulator 1
6 5500-13130 Gasket, carb 1
7 0263-90520 Screw, M5x20 2
8 5516-15100 Muffler assy 1
9 5516-15110 Muffler 1
10 1601-15120 Arrester 1
11 5516-15160 Bolt,M5x75 2
12 5516-15210 Gasket, muffler 1
13 5500-15220 Plate 1
14 0263-90416 Screw, M4x16 1
15 5500-21100 Crankcase comp 1
16 5500-21140 Gasket 1
17 06030-06001 Bearing 2
18 2169-21210 Seal 1
19 1850-21220 Seal 1
20 04065-02812 Snap ring 1
21 01252-30530 Bolt, M5x30 4
22 5500-22110 Guard 1
23 0263-90514 Screw, M5x14 1
24 5600-41111 Piston 1
25 1100-41210 Ring 2
26 1101-41310 Pin 1
27 1260-41320 Ring 2
28 1140-41330 Bearing 1
29 1101-41340 Washer 2
30 5500-42001 Crankehaft comp 1
31 5516-43230 Extention 1
32 1000-43240 Key 1
33 5501-71110 Rotor 1
34 5501-71201 Coil assy 1
35 5500-71220 Cord 1
36 2616-71320 Cap 1
37 1900-72111 Cap, Plug 1
38 1900-72120 Spring 1
39 5500-72130 Grommet 1
40 1260-71261 Spacer 2
41 3310-72150 Bolt, M4x25 2
42 5500-75100 Recoil assy 1
43 1850-75120 Reel 1
44 1850-75130 Spring 1
45 1850-75151 Screw 1
46 1850-75160 Rope 1
47 1140-75320 Knob 1
48 5500-75170 Plate 1
49 1850-75201 Pulley assy 1
50 1850-75221 Ratchet 1
51 1850-75230 Spring 1
52 0263-90416 Screw, M4x16 4
Key# Part Number Description Q'ty
53 5602-73110 Spark plug (RCJ-6Y) 1
54 5500-73201 Cord comp 1
55 6811-75610 Label 1
56 5516-81000 Carburetor assy 1
57 1850-81450 Body assy-pump 1
58 3306-81380 Screen-inlet 1
59 1850-81490 Body assy-air purge 1
60 1850-81520 Cover 1
61 1751-81510 Pump 1
62 3310-81260 Diaphragm-a-met'g 1
63 1850-81470 Gasket 1
64 1065-81420 Diaphragm 1
65 1065-81410 Gasket 1
66 5516-81250 Jet 1
67 1751-81240 O-ring 1
68 1751-81130 Ring 1
69 1881-81140 Swivel 1
70 5516-81150 Valve assy 1
71 1752-81110 Screw 2
72 5500-81120 Bracket 1
73 1751-81180 Nut 1
74 1918-81170 Screw 1
75 1881-81130 Ring 1
76 1850-81530 Screw 4
77 5500-81160 Washer 1
78 ––––––––– ––––––– –
79 0263-90560 Screw 2
80 5516-83101 Cable 1
81 5516-82000 Cleaner assy 1
82 1918-82110 Cover 1
83 1918-82120 Filter 2
84 1918-82130 Housing 1
85 1918-82140 Plate 1
86 5516-82150 Choke valve 1
87 1918-82160 Washer 1
88 1918-82170 Sleeve 2
89 5516-82120 Silencer 1
90 5516-85001 Tank assy 1
91 5600-85202 Cap assy 1
92 5600-85231 Holder 1
93 5600-85240 Cap 1
94 5600-85250 Valve 1
95 5500-85220 Packing 1
96 5580-85300 Pipe comp 1
97 5500-85400 Filter 1
98 1260-85460 Clip 1
99 5516-85510 Screw, M5x20 3
100 5516-85531 Collar 1
101 1950-86120 Clip 1
