Fig.1 ENGINE GROUP HB250
Key# Part Number Description Q'ty
1 6457402 ROTOR 1
2 4309501 CRANKCASE&SHAFT ASSY 1
3 6968501 • BEARING 2
4 5687501 • SEAL 1
5 9071301 GASKET CASE 1
6 6968401 • RING 1
7 5687401 • SEAL 1
8 6634801 • SCREW 3
9 3075003 • CRANKCASE ASSY 1
10 3090101 CRANKSHAFT ASSY 1
11 6457303 PISTON 1
12 6969001 RING 2
13 6969101 CLIP RING 2
14 6968701 WASHER 2
15 6997001 NEEDLE BEARING 1
16 6230101 WRIST PIN 1
17 6968801 KEY 1
18 4300401 PULLEY ASSY 1
19 5516-43230 EXTENTION 1
20 T1513-15100 MUFFLER ASSY 1
21 4810-15140 • ARRESTER 1
22 T4950-57030 BOLT TORX, M5x70 2
23 T1513-15210 GASKET, MUFF 1
30 6457003 CYLINDER 1
31 848-EU2-14B0 GASKET INSULATOR 1
32 5994702 INSULATOR 1
33 9071103 GASKET CABURETOR 1
34 6634402 SCREW TORX 2
35 3074518 CARBURETOR 1
36 6970001 CLIP HOSE 1
37 6969901 CLIP HOSE 1
38 5688002 PLASTIC RUBBER TUBING 1
39 3078001 PRIMER ASSY 1
40 3097402 CHOKE LEVER&PLATE ASSY 1
41 6634501 • SCREW TORX 1
42 5994601 • CHOKE PLATE 1
43 4315001 • CARBURETOR PLATE 1
44 5945801 • CHOKE LEVER 1
45 6634601 BOLT CARBURETOR 2
46 5687301 ELEMENT 1
48 3099904 COVER ASSY 1
49 5946101 KNOB 1
50 9506501 DECAL 1
51 9506009 DECAL(To Start) 1
Key# Part Number Description Q'ty
52 8714402 SPARK PLUG NGK BPMR7A 1
53 6634201 CAP SCREW 2
54 9070901 GASKET CYLINDER 2
55 3075304 RECOIL ASSY 1
56 6635101 SCREW TORX 4
57 9506010 DECAL(E Start) 1
58 848-L0F-90D0 DECAL(EMISSION) 1
61 848-EU2-8500 TANK ASSY 1
62 T1015-85202 • CAP ASSY 1
63 4500-85300 • • HOLDER ASSY 1
64 4500-85220 • • PACKING 1
65 5601-85260 • • FILTER 1
66 4820-85260 • • STOPPER 1
67 848-EU2-8530 • PIPE COMP. 1
68 3302-85400 • FILTER ASSY 1
69 2841-31280 • COLLER 1
70 4820-85510 BOLT TORX, M5x16 3
71 6634901 BOLT TORX 2
72 3075204 COIL&BOOT ASSY 1
73 T1513-71240 CORD 1
74 1900-72112 CAP 1
75 1900-72120 SPRING 1
76 T1513-71320 TUBE 1
77 5500-72130 GROMMET 1
78 5946201 SPACER 2
79 6996901 WASHER 2
80 2630-31950 SCREW 1
81 1484-86280 WASHER 1
82 5516-83101 CABLE 1
