10
• Install the pushrod with the included
hardware.
From the Pro: It is essential that you install the side
with the standoff toward the control horn and use a
small washer on the outside of the ball link. This will
prevent the ball joint from slipping off under load.
NOTE: It is easier to install the rudder,
tailwheel, and pull-pull linkage before mounting
the Horizontal stabs to the fuselage.
•Install the Elevator servo extensions to the
fuselage. Then, insert the carbon fiber stabilizer
tube to the
fuselage.
DO NOT
GLUE!
•Locate the stabilizer hardware and place
washers as shown below.
•Install the stabilizer halves onto the carbon
fiber tube, connect the servo leads, and secure
using the screws with a drop of thread locking
compound on each.
From the Pro:
Use heat
shrink tube to
secure the
servo lead to
the extension.
To Next Page
