22
OPTIONAL:
Install the side force generators (SFG’s) to the
wing tips. The SFGs are installed using the
button-head screws provided with a drop of
thread locking compound on each screw. There
are blind nuts preinstalled in each wing tip.
Receiver and Setup
The receiver will typically be located behind the
wing tube support or on the rudder servo tray
with the batteries placed to achieve the proper
balance of the model. Make all connections and
use a soft mounting to help isolate from
vibration.
Center of Gravity
For your first flights set the CG 6.75” from the
leading edge at the root of the wing. This is
near the front edge of the wing tube and will be
close to neutral. After checking the CG in flight
you can adjust for your personal flying style.
Control throws: -- DR/Expo --
LOW MED HIGH
AIL 1.75”/30% 2.75”/40% 4”/60%
ELE 2.5”/30% 3.25”/ 40% 4”/55%
RUD 2.5”/20% 3”/ 30% 4.25”/40%
