19
•Once all holes have been drilled, you may
reinstall the engine for final assembly using
thread lock compound.
•Install the throttle servo and the linkage to the
carburetor.
--The PTE72cc Twin allowed for a short, straight
throttle linkage so we used a ball-link set (NOT
INCLUDED) we had on hand from a previous
model. Control rod and linkage stopper are
included in the hardware.
From the Pro: The throttle arm on the carb and the
servo horn should be of the same length to allow use
of full servo resolution and better/finer throttle
control.
Ignition Module
•Choose a location for the ignition model a few
inches or more away from the throttle servo if
possible.
•Mark and drill four 3/8 inch holes in the chose
position on the motor box for securing the
module with zip ties.
•Secure into position using
sticky backed Velcro and
secure with zip ties.
