16
•Locate the landing gear hardware and carbon
fiber joiner plate.
•Install the blind nuts into the inner mounting
holes in the fuselage.
From the Pro: To
ensure the blind nuts
stay in place: Use a
drop of CA gel or 15
min epoxy on the
blind nut flange
before installing.
•Then secure the main gear to the fusealage
with the joiner plate following these steps as
shown.
NOTE: The outer bolts are
secured thru the aluminum
support using the supplied
lock nuts. - - use thread lock
when threading into the blind
nuts.
•Next, secure the landing gear fairings to the
fuselage using canopy glue or button head
screws (not included) into the stringers.
•Locate the wheel pants and hardware shown
below.
•Install the blind nuts into the
pre-drilled holes.
