DVS SERIES AIR HANDLER MANUAL
28
Power Requirements 120 VAC, 1PH
MaximumFuse 15Amps
Total Amps 6 Amps
Transformer 30 VA
Blower Motor 3/4 HP ECM
Pump 1/25 HP 3-Speed
FilterSize 16”x20”x1”
ReturnDuctConnectionSize 14”x18”
Unit Technical Information
Airflow Water Return Supply Output Supply Leaving CSA P.9-11
CFM Flow Air Water BTU Air Water Certified
GPM Deg F Deg F Deg F Deg F Condition
120 36,000 104 91 -
130 43,300 112 95 -
1000 2.5 70 140 50,700 118 99 -
150 58,200 124 103 -
160 65,600 131 106 -
Heating Capacity
Motor Speed CFM at 0.4” E.S.P. CFM at 0.8” E.S.P.
Low Velocity (0.4”) Normal 1,005 890
Low Velocity (0.4”) Boost 1,080 970
Mid Velocity (0.8”) Normal 1,130 1,010
Mid Velocity (0.8”) Boost 1,205 1,110
Blower Capacity
DVS1000 SPECIFICATION
