RedZone DVS400 - Air Delivery Performance

25
DVS400 SPECIFICATION
Power Requirements 120 VAC, 1PH
MaximumFuse 15Amps
Total Amps 3 Amps
Transformer 30 VA
Blower Motor 1/3 HP ECM
Pump 1/25 HP 3-Speed
FilterSize 12”x20”x1”
ReturnDuctConnectionSize 11”x18”
Unit Technical Information
Airflow Water Return Supply Output Supply Leaving CSA P.9-11
CFM Flow Air Water BTU Air Water Certified
GPM Deg F Deg F Deg F Deg F Condition
120 14,800 105 90 -
130 18,700 114 92 -
400 1 70 140 22,000 121 95 Yes
150 25,100 129 99 -
160 28,300 136 102 -
Heating Capacity
Motor Speed CFM at 0.4” E.S.P. CFM at 0.8” E.S.P.
Low Velocity (0.4”) Normal 410 240
Low Velocity (0.4”) Boost 480 340
Mid Velocity (0.8”) Normal 550 400
Mid Velocity (0.8”) Boost 610 480
Blower Capacity
