DVS1200 SPECIFICATION
Power Requirements 120 VAC, 1PH
MaximumFuse 15Amps
Total Amps 7 Amps
Transformer 30 VA
Blower Motor 3/4 HP ECM
Pump 1/25 HP 3-Speed
FilterSize 18”x20”x1”
ReturnDuctConnectionSize 16”x18”
Unit Technical Information
Airflow Water Return Supply Output Supply Leaving CSA P.9-11
CFM Flow Air Water BTU Air Water Certified
GPM Deg F Deg F Deg F Deg F Condition
120 42,200 103 92 -
130 50,800 110 96 -
1200 3.0 70 140 59,400 116 100 -
150 68,100 123 104 -
160 76,800 130 108 -
Heating Capacity
Motor Speed CFM at 0.4” E.S.P. CFM at 0.8” E.S.P.
Low Velocity (0.4”) Normal 1,202 1,090
Low Velocity (0.4”) Boost 1,280 1,180
Mid Velocity (0.8”) Normal 1,300 1,205
Mid Velocity (0.8”) Boost 1,390 1,300
Blower Capacity
