Reebok B4.5s - Page 18

Version 1.3
Copyright by
Reebok 2007
ENG 18
www.rbkfitness.com www.rbkfitness.de
NO PART NAME SIZE Q'TY NO PART NAME SIZE Q'TY
24 FLANGE NUT 2 71 ROUND PLATE 16.8*3
2
25 CRANK COVER 2 72 SPRING
2*16*30 1
26 PEDAL ( L ) VP386 1 73 BRAKE AXLE BOLT 10*101.5
1
27 CRANK ( R )
170
SPINBIKE
1 74 SPRING 2 1.5*15*25
1
28 PEDAL ( R ) VP386 1 75 BRAKE NUT 2 16.8*16.8*25
1
29 FLYWHEEL
13KG
Φ450*28
1
76 FLANGE NUT M8*P1.25
2
30 BEARING 6001ZZ NBK 4 77
BRAKE ADJUSTMENT
DRUM
20*30
1
31 FRONT PULLEY 1 78 NYLOCK NUT M6
1
32 LOCK RING
Φ42.5*4
SPHC
1 79 BOLT M6*20
2
33
ALXE OF
FLYWHEEL
14*185
SCM415
2
80
BELL CRANK FOR
BRAKE PAD
30*3*66.5 1
34 WASHER 12.2*16.6*1 4 81 SPACER
Φ6.2*Φ10*6.2
2
35 NUT M12*P1.5
6
82 BRAKE PAD 25*112
1
36 BRACKET
19*4
2 83 PAD 25*7*115 1
37 FLANGE WASHER 13*20*2 2 84 PVC GASKET
176*59*1.5
PVC
2
38
SLEEVE FOR
FLYWHEEL AXLE
12.25*16*11 1 85
RUBBER STOP
INSERT FOR
HANDLEBAR TUBE
12*92 1
39
INSERT SLEEVE
FOR HANDLEBAR
1 86 WASHER
Φ8*Φ18*1.0
2
40
NUT M8*P1.25 4
87 NUT M10 1
41 BOLT M8*50*P1.25 2 88 SADDLE DD6801 1
42 FLYWHEEL PLATE 390*2 PP 2 89 NUT M6 1
43 BOLT M4*12 6 90 WASHER
Φ11*Φ21*1.5
1
44
RUBBER STOP
INSERT
8*92
1 91 MOVE SLOT 1
45 HANDLEBAR 1 92 PUSLE WIRE 600mm 1
46
INSERT SLEEVE
FOR SADDLE
36*93*259 2 93 MIDDLE WIRE 1
47
HANDELBAR
SUPPORT STEM
30*60*1 1 94
USER’S MANUAL – Indoor Bike
