NO. PART DESCRIPTION QTY
A01 base frame 1
A02 main frame 1
A03 incline bracket 1
A04 console bracket 1
A05 pulse bracket 2
A06 left upright tube 1
A07 right upright tube 1
A08 motor bracket 1
B01 front roller 1
B02 back roller 1
B03 cylinder 1
B04 spanner and screw driver 1
B05 5mm allen key 1
B06 bushing 4
B07 transport wheel bushing 4
B08 speaker net 1
B09 pulse steel plate 4
B10 spring plate 2
B11 Reinforcement tube 1
B12 locking pin 1
B13 belt hook 2
B14 hide board 2
C01 console top cover 1
C02 console bottom cover 1
C03 console back cover 1
C04 console panel 1
C05 console panel bottom cover 1
C06 left water bottle 1
C07 right water bottle 1
C08 pulse top cover 2
C09 pulse bottom cover 2
C10 handle bar 2
C11 decoration strip i 1
C12 decoration strip ii 1
C13 handle bar decoration ring 2
C14 motor top cover 1
C15 left upright tube cover 1
C16 right upright tube cover 1
C17 back end cover 1
C18 left side rail 1
C19 right side rail 1
C20 anti-slip pad 2
C21 sticker of anti-slip pad 2
C22 cushion 2
C23 air cushion 4
C24 safety key base 1
NO. PART DESCRIPTION QTY
C25 volume control button 1
C26 base of volume control button 1
C27 fan 1
C28 fan guide 1
C29 fan axis 1
C32 running belt 1
C33 motor bottom cover 1
C34 black cushion 4
C35 blue cushion 2
C36 blue cushion 2
C37 plastic pad 4
C38 motor belt 1
C39 transport wheel 2
C40 adjustable wheel 2
C41 ring-shape wire plug 2
C42 flat foot pad 4
C43 cone-shape cushion 1
C44 plastic holder 1
C45 button board 1
D01 computer board 1
D02 control board 1
D03 top signal wire 1
D04 middle signal wire 1
D05 bottom signal wire 1
D06 pulse button 2
D07 safety key 1
D08 AC single wire 200mm blue 1
D09 AC single wire 200mm brown 2
D10 AC single wire 350mm brown 1
D11 AC single wire 350mm blue 1
D12 grounding wire 1
D13 power wire 1
D14 power socket 1
D15 on-off button 1
D16 overload protector 1
D17 magnet ring 1
D18 magnet core 1
D19 incline motor 1
D20 DC motor 1
D21 running board 1
D22 speaker 2
D23 audio board 1
D24 USB board 1
D25 volume control board 1
D26 console panel sticker 1
D27 function button sticker 1
NO. PART DESCRIPTION QTY
D28 filter 1
D29 inductance 1
D30 speed sensor 1
E01 nut (M6) 2
E02 nut (M8) 12
E03 nut (M10) 6
E04 bolt (M10*60 L20) 1
E05 bolt (M10*45 L15) 1
E06 bolt (M10*30 L15) 4
E07 bolt (M8*50 L15) 4
E08 bolt (M8*50 L20) 2
E09 bolt (M8*45 L20) 5
E10 bolt (M8*40 L20) 2
E11 bolt (M8*30 L15) 1
E12 bolt (M8*20) 4
E13 bolt (M8*15) 8
E14 bolt (M8*45) 1
E15 bolt (M8*35) 1
E16 bolt (M6*55) 3
E17 bolt (M6*35) 2
E18 bolt (M6*25) 6
E19 bolt (M5*16) 4
E20 bolt (M5*12) 4
E21 bolt (M5*8) 17
E22 screw (ST4.2*40) 8
E23 screw (ST4.2*30) 4
E25 screw (ST4.2*20) 2
E26 screw (ST4.2*12) 34
E27 screw (ST4.2*12) 22
E28 screw (ST2.9*8) 30
E29 screw (ST2.9*6) 6
E30 screw (ST4.2*15) 4
E31 washer (Ø6) 3
E32 washer (Ø8) 14
E33 washer (Ø10) 2
E34 spring washer (8) 6
E35 flat washer (8) 11
E36 big washer (10) 8
E37 screw (ST3.5*12) 7
E38 bolt (M8*35 L20) 6
