Part Name QTY Part Name QTY
1 Frame 1 36 Idler Flexing spring 1
2 Seat Post Lock Knob 1 37 Left Chain cover 1
3 Seat Post Sleeve 1 38 Right Chain cover 1
4 Bearing 6003ZZ 2 39 Upright lower cover 1
5 Belt wheel 1 40 Plastic insert 6
6 Sensor magnet 1 41 Upright lower insert 1
7 Crank Shaft 1 42 Upright 1
8 Bushing 1 43 Middle Computer wire 1
9 C-Clip 1 44 Philips Screw M5x15 2
10 Crank Shaft Screws 4 45 Crank cover 2
11 Nylon Nut 4 46 Crank arm screw 2
12 Spring washer 4 47 Idler wheel fixing iron plate assembly 1
13 Wave washer 2 48 Handlebar 1
14 Flat washer 2 49 Foam Grip Upper 2
15 Drive Belt 1 50 Foam grip lower 2
16 Belt 2 51 Line Plug 2
17 Control Board 1 52 Pulse sensor housing 4
18 Sensor Wire 1 53 Hand pulse sensor 4
19 Lower Control Wire 1 54 Fixing Tape 4
20 Sensor Fixed Base 1 55 Round head Philips screw 4
21 Round head screw 3 56 Nut 4
22 Lower control connecting wire 1 57 Handlebar end caps 2
23 Power Wire 1 58 Front stabilizer 1
24 Belt 2 59 Stabilizer wheel housing 2
25 Fly wheel 1 60 Stabilizer end cap 4
26 Column head hex screw 4 61 Stabilizer wheel 2
27 Washer 4 62 Stabilizer adjustment foot 4
28 Spring washer 4 63 None
29 Crank arm left 1 64 None
30 Crank arm right 1 65 Rear stabilizer 1
31 Jockey Wheel 1 66 None
32 Bushing 1 67 Seat Post 1
33 Flat hex screwM10x32mm 1 68 Saddle adjustment bracket 1
34 WasherØ25xØ10.2x3.0t 1 69 Saddle bracket end cap 2
35 Nylon nut 2 70 Slider bracket 1
TC3.0 PARTS LIST
Part Name QTY
71 Seat adjustment knob 1
72 Saddle 1
73A. Seat tube cover left 1
73B. Seat tube cover right 1
73 Seat tube cover rear 1
75 Computer 1
76 Power adaptor 1
77 Handlebar adjustment knob 1
78 Upright upper cover rear 1
79 Upright upper cover front 1
80 Upright bolt M8x20 4
81 Arc washer 4
82 Cross head screw 20
83 Water bottle holder 1
84 Stabilizer bolt 4
85 Spring washer 8
86 Flat washer 4
87 Cross head screw 1
88 Allen Key 1
89 Philips open end wrench 1
91 Pulse sensor wire 2
92 Upper computer wire 1
93 Computer screws 4
94 Strap 4
95 Iron core 2
97 Idler plate sleeve 1
1A. Pedal and strap left 1
1B. Pedal and strap right 1
