Part Name QTY Part Name QTY
1 Frame 1 36 Idler tension spring 1
2 Seat post lock knob 1 37 Left chain cover 1
3 Seat Post Sleeve 1 38 Right chain cover 1
4 Bearing 6003ZZ 2 39 Upright Lower Cover 1
5 Belt Wheel 1 40 Handlebar insert 6
6 Sensor Magnet 1 41 Upright lower insert 1
7 Crank Shaft 1 42 Upright 1
8 Bushing 1 43 Middle Computer Wire 1
9 C Clip 1 44 Philips Screw 2
10 Crank Shaft Screws 4 45 CRANK COVER 2
11 Nylon Nut 4 46 Crank Screw 2
12 Spring Washer 4 47 Fixing Plate 1
13 Wave washers 2 48 Handlebar 1
14 Flat washers 2 49 Foam Grip - Upper 2
15 Drive Belt 430J6 1 50 Foam Grip - Lower 2
16 Power Cord 2 51 Line plug 2
17 Adjust tight wire 1 52 Pulse sensor housing 4
18 Sensor wire 1 53 Hand Pulse Sensor 4
19 Lower control wire 1 54 Fixing tape 4
20 Sensor Fixed Base 1 55 Round head philips screw 4
21 Round head screw 1 56 Nut 4
22 Motor 1 57 Handlebar end caps 2
23 Round head cross screws 4 58 Front Stabilizer 1
24 Girding 2 59 Stabilizer wheel housing 2
25 Flywheel 1 60 Stabilizer End Cap 4
26 Flange nut 1 61 Stabilizer Wheel 2
27 Hexagon nut 1 62 Stabilizer adjustment foot 4
28 Washer 2 63 None
29 Crank Left 1 64 None
30 Crank Right 1 65 Rear Stabilizer 1
31 Jockey Wheel 1 66 None
32 Casing pipe 1 67 Seat Post 1
33 Flat head screw M10x38mm 1 68 Saddle adjustment bracket 1
34 Flat head screw M10x20mm 1 69 Saddle bracket end caps 2
35 Nylon Nut 2 70 Slider Bracket 1
Part Name QTY
71 Seat adjustment knob 1
72 Saddle 1
73A. Seat tube cover left 1
73B. Seat tube cover right 1
73 Seat tube cover rear 1
75 Computer 1
76 Power adaptor 1
77 Handlebar adjustment knob 1
78 Upright upper cover - rear 1
79 Upright upper cover - front 1
80 Upright bolt M8x20 4
81 Arc Washer 4
82 Cross head screw 20
83 Water Bottle Holder 1
84 Stabilizer Bolt 4
85 SPRING WASHERS 8
86 Flat washers 4
87 Cross head screw 1
88 Allen Key 1
89 Philips open end Wrench 1
90 Hex wrench 1
91 Pulse sensor wires 2
92 Upper computer wire 1
93 Computer screws 4
94 Strap 3
95 iron core 2
1A. Pedal and strap - left 1
1B. Pedal and strap - right 1
TC1.0 PARTS LIST
