HIDEAWAY
ACTIVE SENSOR-FLUSH URINAL
Plumbers, please ensure a copy of the installation
instructions is left with the end user for future reference
HIDEAWAY
ACTIVE SENSOR-FLUSH URINAL
9.0 System Description and Technical Specification
0.8 litre Active Urinal with Hideaway Smart Demand Operation and Urine Sensing Device
• The Sensor detects urine entering the urinal bowl and initiates a flush accordingly.
• The Controller is equipped with a flush time adjustment and program selector switches.
• Flush time can be selected depending on available dynamic pressure.
• The Program Selector switch allows the selection of the appropriate setting to maximise water conservation
based on the expected usage as follows:
Program 1 (Normal Mode-Factory setting) flushes after every use and will automatically switch to Saver Mode (1 flush every
minute) when 4 users visit the urinal in less than 1 minute intervals no matter how many times used. 1 minute of non-use will
reset the control unit back to Normal Mode. Janitors Flush activates after 48 hours of non-use.
Program 2 (Eco Mode) flushes after every 3
rd
user or 15 minutes, whichever is first. Janitors Flush activates after 48 hours of
non-use.
• Overflow protection, avoids overflow in the case of a pipe blockage where the urine sensing device ceases to
activate further flushing once the urinal bowl has filled.
• Self-diagnostic fault finding.
• Sensor is concealed to protect against vandlism.
Operating voltage mains powered model:
Operating voltage battery powered model:
Selectable based on available dynamic pressure
Minimum dynamic pressure:
Maximum dynamic pressure:
Minimum connection pipe size:
page 12 of 16
