ALARM OUT Socket
If the socket is set to DC OUT, then, when the radio
receives alerts, the socket will output 6 Volts DC (the
voltage will be less when the radio is only powered with
back-up batteries) to the external device.
(the output polarity is shown underneath the socket)
If the socket is set to SWITCH (as internal POWER
SWITCH), then, when the radio receives alerts, t
turn on the
power of the external device / accessory.
For this function, the socket's electrical maximum
rating is: DC voltage: 12 Volt.
DC current: 350mA.
connected
he
internal power switch will be 'closed' to
connected
Press STOP key to 'open' the internal switch.
Refer to program menu page P8 (SIREN TEST) to test
this function, if necessary.
The ALARM OUT socket is provided on the back of the
radio. The socket's output is compatible with home
automation devices from suppliers such as Plug'n Power,
X-10 or others. Connect a 3.5mm (1/8inch) phone jack
with polarity as indicated underneath the socket.
AUDIO OUT Socket
1. Press and hold PROG key for 2 seconds to enter program
menu page. Skip this step if it is now in program menu.
2. Keep pressing key to menu page P7.
3. Press ENTER key to select.
4. Press key to select DC OUT or SWITCH option.
5. Press ENTER key to confirm.
To exit the program menu, press PROG key.
The socket outputs siren and voice broadcast signal to
the external audio systems such as Public Address
system, external speaker system and etc.
When it is necessary to use this socket, connect the
3.5mm (1/8 inch) phone jack to the socket with polarity
as indicated underneath the socket; the speaker voice is
muted. The volume keys or , controls the audio
output level.
Info
Info
Info
Siren Test
The SIREN TEST menu page P8 lets you to pre-hear
and be familiar with the actual siren / beep tone
generated by the radio when actual alerts / tests
are received.
In addition, the ALARM OUT socket function can
be tested here. If desired, connect the external device
to the socket before proceeding to the steps below.
1. The warning siren, watch siren, advisory siren and
beep tone will be generated respectively each time
you press or ENTER key.
2. The siren / beep tone will last for about 15 seconds.
3. Press STOP key will stop the siren / beep tone.
4. During the siren, the ALARM OUT socket will
output control signal to trigger the external device.
5. When the siren / beep tone stops, press PROG key
to exit program menu page.
Info
Hint
1. Press and hold PROG key for 2 seconds to enter program
menu page. Skip this step if it is now in program menu.
2. Keep pressing key to menu page P8.
3. Press ENTER key to activate siren / beep tone.
- 7 -
