Electrical Specifications
Accuraciesarespeciedby:
±(…%ofreading+…digits)at23ºC±5ºC,below80%RH.
OHMS
Range Resolution Accuracy
Max. open
Circuit Voltage
Overload
Protection
200Ω 0.1Ω
+(1%+2)
4.5V
250Vrms
200kΩ 0.1kΩ 3.0V
Continuity Beeper
Range Resolution
Operation
Resistance
Max.open
Circuit Voltage
Overload
Protection
•))) 0.1Ω Resistance≤40Ω 4.5V 250Vrms
Short circuit current: ≤200mA
DC Voltage
Range Resolution Accuracy
Input
Impedance
Overload
Protection
1000V 1V +(0.8%+3) 10MΩ 1000Vrms
AC Voltage (40Hz~400Hz)
Range Resolution Accuracy
Input
Impedance
Overload
Protection
750V 1V +(1.2%+10) 10MΩ 750Vrms
Meg OHMS
Range Resolution Accuracy Terminal Voltage
200MΩ/250V 0.1MΩ
+(3%+5)
250V+10%~-0%
200MΩ/500V 0.1MΩ 500V+10%~-0%
0~1000MΩ/1000V
1MΩ 1000V+10%~-0%
1000~2000MΩ/1000V +(5%+5)
Range Test Current Short circuit current
200MΩ/250V
1mA
250KΩ(load)
≤1mA
200MΩ/500V 500KΩ(load)
0~1000MΩ/1000V
1MΩ
1000~2000MΩ/1000V
