Instruction Manual DCD-230 English
11
7. Maintenance, cleaning and repair
7.1. Maintenance
The gear unit must be lubricated at regular intervals using normal machine oil.
Remove the hexagon socket screw using the 5mm Allen key supplied.
The electric motor brushes should be replaced, if necessary.
If the safety clutch has been released and the machine runs without the drill
spindle turning, the clutch must be retightened using the internal stop screw.
7.2. Cleaning
Clutch setting and lubrication
connection
Turn approx. 15°
Use small flat-bladed
screwdriver to counter the
locking into position
