Service of manifold
The charging hoses must be checked and free of oil residue before each use. A visible inspection is also neces •
sary to ensure that the hoses and the connection are undamaged and tight.
The seals and gaskets of the manifold are parts of use and must be replaced from time to time. The manifold is to •
be tested regularly to ensure the valves are still tight.
If a manifold shows to be leaking the pistons of the valves can easily be replaced and are available as a spare •
part. Please refer to the manifold accessory section of the REFCO catalog.
If the sight glass is leaking a replacement kit is available. To change the sight glass a special tool is necessary •
(M4-6-11-T) which is available from REFCO. Replace and tighten the new sight glass carefully in order to prevent
damage to the glass.
After installing spare parts to the manifold it is necessary to test the manifold for leaks before the next use.
•
Auto shut-off
Approximately 10 minutes after the last measurement or keypress the DIGIMON shuts off itself.
Disposal of manifold
Dispose of the manifold according to the rules and regulations of the country of use.
Spare parts for DIGIMON manifold
Description Designation Part number
Handwheel red M2-7-SET-R 3080-4677826
Handwheel blue M2-7-SET-B 3080-4677834
Complete valve set M2-10-95-R/10 3080-4662607
Piston incl. gaskets M4-6-04-PA/10 3080-4662624
Sight glass set M4-6-11 3080-4493169
External temperature sensor DIGIMON-EXTERNALSENSOR 3080-4677647
Battery compartment cover DIGIMON-BATTERYCOVER 3080-4676374
Tool for sight glass M4-6-11-T 3080-4493169
Tool for valve core A-32000 3080-9880890
Plastic case DIGIMON-CASE 3080-4676497
English
5
