SAFETY INSTRUCTIONS
The Gobi II Condensate pump is to be installed in accordance with
local and regional electrical codes.
Save these instructions for further reference.
The following symbols related to safety are used on the product or
throughout the product documentation
WARNING/CAUTION
An appropriate safety instruction should be
followed or caution to a potential hazard exists.
DANGEROUS VOLTAGE
To indicate hazards arising from dangerous voltages.
WARNING: Please read all safety instructions and the installation
instructions completely before commencing.
To prevent any risk only certified and appropriately trained sta with
sucient technical training and tools shall install this product.
Product installation and electrical connections both require
professional training for safe installation and correct product operation.
WARNING: Disconnect all electrical power before starting installation,
maintenance, or service work.
WARNING: Disconnect electrical power before removing and checking
internal fuse.
CAUTION: This pump is not submersible and for indoor use and
connection only.
CAUTION: Do not install The REFCO condensate pump if there are
any signs of damage.
WARNING: Check the cables REFCO condensate pump power and
alarm cords prior to, during and periodically for signs of damage.
If either the power or alarm cords are damaged, isolate and disconnect
the condensate pump from service. Contact REFCO for a replacement.
** The Gobi II combined power/alarm cable lead-out is non-replaceable.
lf this is damaged the entire pump must be replaced.
WARNING: The REFCO condensate pump cables should not be cut,
and should be routed so that they cannot be damaged during and after
installation.
CAUTION: All tubing connections are to be secured in place on the
barb connections using self-locking cable tie-wraps.
DO NOT use tools to connect the tubing.
DO NOT operate this product in ambient temperatures below 5 °C
(41 °F).
DO NOT operate with incoming water above a temperature of 40 °C
(104 °F).
CAUTION: Do not allow any chemicals to come in contact with this
condensate pump. Please remove the pump and water sensor before
using any coil cleaning solutions and other chemicals. Flush the
evaporator coils with water before re-installing the condensate pump
and water sensor.
Ensure the coils are chemical free before reinstallation.
CAUTION: In all installations where any property damage and or
personal injury may result from an inoperative, failed, incorrectly
installed or leaking condensate pump, it is strongly recommended
that the alarm relay shall be used in fail-safe mode to completelyshut
down the air conditioning unit, should a pump failure occur.
2
Technical specification Gobi II
Power rating: 100
-
240V, 50-60 Hz, 8W Class II
Alarm relay: Interchangeable NO or NC, rated 250V, 10A Max or 28VDC, 10AMax
Minimum flow rate: 42 l/hr. (11 GPH)
Maximum suction: 3.0 m (10 ft.)
Maximum head: 20.0 m (65.60 ft.)
Sound: 20dBA at 1 m (3 ft.) / 19dBA at 1 m EN ISO 3744:2010
Discharge star tube: 6.25 mm (1/4“) ID, 1m (3.3 ft.) in length
Overall dimensions: 250 x 340 x 54 mm (9.84 x 11.81 x 2.1 inches)
Bulk pack: 10 Pcs dimensions are 590 x 265 x 365 mm (23.2 x 10.4 x 14.4 inches)
Color: RAL #9003 white
Weight: 600g (1.3 lbs.)
Operation temperature: Ambient & water 5-40°C (41-104°F)
Compliance: Conforms to UL: 778 and Certified to CSA C22.2 #68
