English Instruction Manual LFT-230
14
Move the control stick into the required position and carefully press the yellow
operating switch.
Press gently for a slow lifting/lowering speed. Press firmly for a faster lifting/lowering
speed.
Always adjust the lifting/lowering speed in accordance with the lift load.
Ensure that the load is secured before lifting or lowering the device!
The safety catch disengages the
gearbox unit if the operating switch
remains pressed after the maximum
lowered height has been reached
(causing a loud rattling noise), thereby
preventing the wire cable from coiling in
the wrong direction.
The device is fitted with a load-limiting device that disengages the
gearbox unit if required (causing a loud rattling noise). It also
disengages automatically when the maximum lift height is reached.
6.4. Activation of the emergency stop button
Press the red button to stop the
machine immediately in a hazardous
situation.
