METHOD OF CONNECTION
INPUT: Connect the tonearm leads and
earth (if used) to the input socket and to the
earth terminal on the back of the Fono.
TURNTABLE EARTH: If the turntable or tonearm
has a separate signal earth connection,
this should be connected to the turntable
earth terminal on the back of the unit.
OUTPUT: Connect the output socket of the
Fono to the line input on the amplier.
PLEASE NOTE: If you have an integrated
amplier with built in phono stage, DO
NOT connect the Fono to this input.
POWER SUPPLY: Connect the Rega PS1 to
the AC socket on the Fono back panel.
POWERING UP
The Fono MM is turned on by pressing the
on-o button located on the front, when the
unit is active the Rega logo will glow RED.
WARNING: We advise you to turn the Fono
on rst, followed by the amplier. This
is because the power surge in the Fono
could cause an audible, power on “thump”
which may distress the speakers.
1. INPUT
2. OUTPUT
3. TURNTABLE EARTH
4. AC SOCKET
1 2 3 4
www.rega.co.ukEN

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Rega FONO MM MK5 and is the answer not in the manual?

Rega FONO MM MK5 Specifications

General IconGeneral
Input Loading47kΩ in parallel with 100pF
Output Impedance200Ω
Gain41.4dB
Power Requirements24V AC
Signal to Noise Ratio78dB
TypeMoving Magnet
THD0.01%
Power SupplyRega PS1
