103
Systems
CHEMICAL TOILET
Installed as standard equipment on your vessel is a self-
contained sanitation device known as a chemical toilet
featuring an upper fresh water tank and a lower deodorized
tank. These two components can be separated for waste
disposal, cleaning and relling. The lower tank contains a
capacity gauge. Before each outing, check the waste level
since it is illegal to dump waste within and extending out
to the United States territorial limit.
Refer to a typical system shown on the following page. For
more information, review the vendor manual supplied in
the owner’s information packet or visit the on-line location.
FLUSHING BELLOWS
HOLD DOWN
BRACKET
LIFT & PULL FORWARD
TO REMOVE HEAD UNIT
DEODORIZED WASTE TANK
FRESH WATER TANK
To Next Page
