26 EXPRESS DIMENSIONS (APPROXIMATE)
REFERENCE ONLY
CVL
REV. DATEDR. BY
REV
JA
10/16/15
A
Updated dimensions and overall profile
APP. BY
REVISION DESCRIPTION
DR
26 Ex Critical Dimensions
LHN11B
PROPRIETARY AND CONFIDENTIAL:
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF REGAL MARINE
INDUSTRIES. ANY REPRODUCTION IN PART OR AS WHOLE WITHOUT THE WRITTEN
PERMISSION OF REGAL MARINE INDUSTRIES IS PROHIBITED.
REVISION:
DRAWN BY:
DRAWING TITLE:
APPROVED BY:
DATE:
2300 JETPORT DRIVE
ORLANDO, FLORIDA 32809
TEL (407) 851-4360
REGAL MARINE INDUSTRIES
PAGE:
ALL RIGHTS RESERVED
DWG. NO.:
JAL
1 OF 1
A
4/8/15
10'-7 1/2"
6'-10 3/4"
8'-6 1/2"
2'-11"
1'-1 3/4"
1'-7 3/4"
9'-0"
1'-3 3/4"
LOA (W/ anchor) 27'-1 1/2"
LOA 26'-0 1/4"
22'-8 3/4"
Water Line
