26 Ex Horizontal Field of Vision
JAL
REGAL MARINE INDUSTRIES
REVISION:
4/8/15
16
15.0°
15.0°
30.0°
67.5°
90.0°
90.0°
112.5°
26 EXPRESS RANGE OF VISIBILITY
