74
Chapter 4
TYPICAL 12 VOLT HELM SWITCH PANEL DESCRIPTION
HORN- toggles the horn system signals as needed.
BILGE BLOWER- controls power ventilation blower.
BILGE PUMP- controls engine room bilge pump.
NAV/ANC- energizes the bow navigation lighting and
all around lighting.
COCKPIT LTS- protects the LED cockpit deck cockpit
lights.
WIPER- activates the driver side windshield wiper.
UNDERWATER LTS- energizes the optional transom
mounted underwater lighting system.
ARCH- activates the radar arch dual actuator system
which drives the hydraulic rams to raise and lower arch.
WINDLASS- activates the optional windlass up and
down anchor system.
Note: Remember that the forward windlass system
on and off switch (looks like a battery switch) must
be turned to the on position for the windlass system
to operate. This switch is used as a safety net to keep
the windlass from accidently operating up or down.
LOCK-OUT SWITCH- Controls power to the up and
down windlass switch. To activate the switch you need to
rock it forward and press the red button to unlock it.
