Chapter 7
MID CABIN- CONVERSION TO BERTH
This illustration shows the normal mid berth seaating posi-
tions. To convert the seating to a berth do the following:
1. Lift the port cushion shown. It uses a gas assisted ram.
Under the port cushion is a fi ller cushion.
2. Remove the fi ller cushion.
3. Set the fi ller cushion on the supports located on the
starboard and port bunk framework.
4. Slide the cushion in place to complete the berth set-
up.
Port
Cushion
Filler Cushion
Port
Cushion
Starboard
Cushion
Supports
