20
Chapter 4
FORE DECK LT.- protects the deck light circuit.
FWD. BILGE- protects the forward bilge pump circuit.
AFT BILGE- protects the aft bilge pump circuit.
NAV/ANCHOR- protects all navigation lights.
COCKPIT LTS.- protects the cockpit light circuit.
ARCH LTS.- protects the hardtop light circuit.
PANEL LTS.- protects the helm (dash) back-lit icons.
HELM SEAT- protects the helm seat’s movement cir-
cuitry.
HORN- protects the air horn located on the hardtop
WINDSHIELD VENT- protects the fresh air wind-
shield vents.
WIPER- protects the starboard windshield wiper cir-
cuit.
WINDLASS REMOTE- protects the deck mounted
foot petals.
FUEL TRANSFER- protects the sump mounted trans-
fer pump. Used for diesel installations.
12 VOLT- protects the accessory plug circuitry.
.
ACC.- protects any aftermarket equipment added by the
owner.
ENGINE RM LTS.- protects the cockpit refrigerator
circuit.
GAS VAPOR- protects optional gas vapor detector cir-
cuiitry.
ENGINE HATCH- protects the hatch opening mecha-
nism.
STEREO MEMORY- protects the stereo memory cir-
cuit.
TRIM TABS- protects the transom mounted electric-
hydraulic trim tab circuit.
SPOTLIGHT- protects the deck mounted light circuit-
ry.
ACC.- protects any aftermarket equipment added by the
owner.
VHF- protects the marine radio circuitry.
RADAR PLOTTER- protects the optional closed array
radar circuitry.
GPS PLOTTER- protects the helm mounted GPS cir-
cuitry.
AUTO PILOT- not used.
DEPTH SOUNDER- not used.
ACC.- protects any aftermarket equipment added by the
owner.
TYPICAL 12 VOLT HELM BREAKER SUB PANEL DESCRIPTION
Note: Select equipment breakers are dedicated for optional equipment and may not be found on your boat.
