SHIP’S MAIN PANEL AC BREAKER DESCRIPTION (TYPICAL)
BREAKER TYPE AC AMPERAGE BREAKER TYPE AC AMPERAGE
SHORE 1
30
SHORE 2
30
30 30
GENERATOR
60
TRANSFER
50
60 50
AIR CONDITIONER-
AFT*
NOT USED
AIR CONDITIONER-
FORWARD
30
A/C PUMP 5 BATTERY CHARGER 15
FWD. OUTLETS 15 ICEMAKER 15
MICROWAVE 15 REFRIGERATOR 10
AFT OUTLETS 15 ACC. 15
STOVE 20 WATER HEATER 15
Note: Refer to main ship’s panel illustration as needed.
*On newer panels the aft air conditioner and A/C pump
breakers have been eliminated since there is only one air
conditioner on this vessel
