6
DRAWING NO. 1
A) REGAL Model ECS401
Single Cylinder Electronic Scale
B) REGAL Model ECS402
Dual Cylinder Electronic Scale
C) Scale Base Installation
TOP VIEW
SIDE VIEW
DIMENSIONS = INCHES (MILLIMETERS)
REGAL SERIES 400 SCALE BASE
REGAL SERIES 400
SCALE BASE
CYLINDER STOP
"L" BRACKET
2.00 (50.8) FROM WALL
13.50 (342.9)
13.00
(330.2)
38 (965.2) -
40 (1016.0)
16.00
(406.4)
2.00
(50.8)
FROM
WALL
REGAL
A-816
S
WITCHOVER
G
AS
R
EGULATOR
HEAD
AC POWER SOURCE
4
-20 mA OUTPUT(S)
A
ND/OR ALARM RELAYS
AC POWER SOURCE
4-20 mA OUTPUT(S)
AND/OR
A
LARM RELAYS
S
AFETY
C
HAIN
WALL
BRACKET
REGAL A-820
G
AS REGULATOR
H
EAD
SAFETY CHAIN
WALL BRACKET
