7
DRAWING NO. 2 - MODEL ECS4011 AND ECS402 MONITORS
A) Single Cylinder (Model ECS401) Electronic Scale Monitor
B) Dual Cylinder (Model ECS402) Electronic Scale Monitor
3.63 (92.202)
5.20 (132.08)
7.06 (179.324)
7.87 (199.898)
4.25 (107.95)
4.75 (120.65)
7.06
(179.324)
7.87
(199.898)
5.80
(
147.32)
6.30
(160.02)
DIMENSIONS = INCHES (MILLIMETERS)
ELECTRONIC SCALE
ELECTRONIC SCALE
