Bimini Top (Typical)- PowerTower (Continued)
TYPICAL BIMINI TOP WITH POWERTOWER PARTS DESCRIPTION
Note that the bimini top hardware shown is in the lay
down position (unattached to the hardware).
Note the photo on the next page with the top in place
and the hardware connected.
JAW W/ LANYARD/PIN
SLIDING JAW
AT BOTTOM
TO START
90 DEGREE
ARM-AFT
BOW
STRAIGHT
ARM
FORWARD
STRAP
SLIDING BOW
ARM
RETAINER
BLOCK
BOW
FIGURE A
