144
Toilet-Electric (12 Volt)
As optional equipment an extra low profile marine
toilet provides a comfortable design and reliable
macerator toilet high performance. This toilet
uses the consolidated ECO smart flush which
consumes less power and water.
This unit uses a metal fresh water tank for
supplying water for the flushing cycle through
a pressurized water pump that is activated by
solenoid technology and a rocker switch. Once
flushed waste is chopped up by a macerator pump
located at the toilet bowl discharge.
Read and understand your toilet owner’s manual
before operating or servicing this system.
Read, understand, and follow the warnings below ;
AVOID SERIOUS INJURY DO TO HIGH
SPEED MOVING PARTS!
DISCONNECT POWER TO THE TOILET
BEFORE SERVICING! NEVER PLACE
HANDS OR FINGERS IN THE BOWL
DISCHARGE BECAUSE OF THE HIGH
SPEED MACERATOR IMPELLER PLACED
DIRECTLY BELOW THE BOWL DISCHARGE.
NEVER ATTEMPT TO DISLODGE AN OBJECT
IN THE PUMP BY PLACING HANDS/FINGERS
IN PUMP AREA WHILE IT IS RUNNING!
WARNING
AVOID SERIOUS INJURY!
PROVIDE SUPERVISION FOR CHILDREN
WHEN USING THE TOILET.
DO NOT PUT BODY PARTS INSIDE TOILET!
WARNING
As optional equipment an extra low profile marine
toilet provides a comfortable design and reliable
macerator toilet high performance. This toilet
uses the consolidated ECO smart flush which
consumes less power and water.
Operation-
The ECO switch located near the head controls
the smart flush cycling. To flush the toilet do the
following:
1. Ensure the battery switch is activated on the
vessel. This assures 12 volt power to the toilet.
2. Activate the fresh water switch that controls the
fresh water pressure pump.
ECO SWITCH
