LS4 (DH) Deck Plan
PROPRIETARY AND CONFIDENTIAL: THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF REGAL MARINE INDUSTRIES. ANY REPRODUCTION IN PART OR AS WHOLE WITHOUT THE WRITTEN PERMISSION OF REGAL MARINE INDUSTRIES IS PROHIBITED.
DRAWING TITLE:
APPROVED BY:
2300 JETPORT DRIVE ORLANDO, FLORIDA 32809 TEL (407) 851-4360
PAGE: DWG. NO.:
11/8/2017
Dennis R.
JPG
1 OF 1
ALL RIGHTS RESERVED
REGAL MARINE INDUSTRIES
DATE:
DRAWN BY:
REVISION:
1
0
7'-1 1/2"
9'-10 1/4"
18'-2 1/4"
24'-3 1/2"
LS4 DIMENSIONS
